ANNKE 8CH Video Security System 5 in 1 H.265+ DVR Recorder 2MP Camera Outdoor Waterproof Protection CCTV Kit 4Camera - 1TB HDD

Name: ANNKE 8CH Video Security System 5 in 1 H.265+ DVR Recorder 2MP Camera Outdoor Waterproof Protection CCTV Kit 4Camera - 1TB HDD
Brand: ANNKE
SKU: AK-DW81KD1-T4GU
Price: 274.99 GBP
Availability: InStock

~~£549.98~~

Sold by ANNKE Security kit

Product information

Description

General description

ANNKE 8CH Video Security System is a comprehensive 5 in 1 H.265+ DVR recorder kit designed for outdoor surveillance. It includes four 2MP cameras that provide high-quality imaging and advanced features for effective monitoring and security.

Technical specifications

Video Compression: H.264+/H.264/H.265/H.265+

Video Input: 8CH Analog HD/Analog + 2CH IP Video (up to 12 channels in IP enhanced mode)

Video Output: HDMI and VGA Up to 1080P

Audio Input: 1-ch RCA, 8-ch via coaxial cable

Audio Output: 1-ch RCA

Supported Camera Types: HD TVI Input (3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p), AHD Input (4MP, 1080p, 720P), CVI Input (4MP, 1080p, 720P), CVBS Input, IP Video Input (6MP/5MP/4MP/3MP/1080P/720P)

Max Playback Channel: 2-ch

Protocols: TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS

Working Temperature: -14 °F – 131 °F / -10 °C – 55 °C

Dimensions (W x H x D): 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)

Weight (without hard disk): ≤ 1 kg (2.2 lb)

Camera Image Sensor: 2MP CMOS

Camera Video Resolution: 1920 (H) × 1080 (V)

Camera Lens: 3.6 mm

Camera Min. Illumination: Color: 0.02 Lux @ (F2.2, AGC ON), 0 Lux with IR

Camera Operating Power: DC12V± 25%, Max. 3.3 W

Camera Dimensions: 85.1 mm × Ø80 mm (3.4" × Ø3.1")

Camera Weight: Approx. 290 g (0.64 lb)

Installation

Installation involves connecting the DVR to the cameras and setting up the system according to the user manual. Ensure that the cameras are positioned for optimal coverage and that the DVR is connected to a power source and monitor.

Usage

The ANNKE Video Security System is designed for both home and business security. Users can monitor live feeds remotely via iPhone, iPad, or Android devices. The system supports motion detection with customizable zones, sending instant alerts when motion is detected in preset areas.
