ANNKE 8CH Video Security System 5 in 1 H.265+ DVR Recorder 2MP Camera Outdoor Waterproof Protection CCTV Kit 4Camera - 1TB HDD

£549.98

You may also like

Compare with similar items

Product information

Description

General description

ANNKE 8CH Video Security System is a comprehensive 5 in 1 H.265+ DVR recorder kit designed for outdoor surveillance. It includes four 2MP cameras that provide high-quality imaging and advanced features for effective monitoring and security.

Technical specifications

  • Video Compression: H.264+/H.264/H.265/H.265+
  • Video Input: 8CH Analog HD/Analog + 2CH IP Video (up to 12 channels in IP enhanced mode)
  • Video Output: HDMI and VGA Up to 1080P
  • Audio Input: 1-ch RCA, 8-ch via coaxial cable
  • Audio Output: 1-ch RCA
  • Supported Camera Types: HD TVI Input (3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p), AHD Input (4MP, 1080p, 720P), CVI Input (4MP, 1080p, 720P), CVBS Input, IP Video Input (6MP/5MP/4MP/3MP/1080P/720P)
  • Max Playback Channel: 2-ch
  • Protocols: TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS
  • Working Temperature: -14 °F – 131 °F / -10 °C – 55 °C
  • Dimensions (W x H x D): 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
  • Weight (without hard disk): ≤ 1 kg (2.2 lb)
  • Camera Image Sensor: 2MP CMOS
  • Camera Video Resolution: 1920 (H) × 1080 (V)
  • Camera Lens: 3.6 mm
  • Camera Min. Illumination: Color: 0.02 Lux @ (F2.2, AGC ON), 0 Lux with IR
  • Camera Operating Power: DC12V± 25%, Max. 3.3 W
  • Camera Dimensions: 85.1 mm × Ø80 mm (3.4" × Ø3.1")
  • Camera Weight: Approx. 290 g (0.64 lb)
  • Installation

    Installation involves connecting the DVR to the cameras and setting up the system according to the user manual. Ensure that the cameras are positioned for optimal coverage and that the DVR is connected to a power source and monitor.

    Usage

    The ANNKE Video Security System is designed for both home and business security. Users can monitor live feeds remotely via iPhone, iPad, or Android devices. The system supports motion detection with customizable zones, sending instant alerts when motion is detected in preset areas.

    Other information

    Features

    • Brand
      ANNKE
    • Width
      8 cm
    • Height
      6.62 cm
    • Weight
      6900 g
    • Material
      Metal
