General description
ANNKE CCTV Kit DVR offers a comprehensive security solution with advanced features for both residential and commercial use. This system includes a 2MP HD TVI turret security camera and a DVR capable of high-definition recording and playback, ensuring that you capture every detail with clarity.Technical specifications
- Video Compression: H.264+/H.264/H.265/H.265 Pro+
- Video Input: 8CH Analog HD/Analog + 2CH IP Video (up to 12 channels when IP enhanced mode is on)
- Video Output: HDMI and VGA Up to 1080P
- Audio Input: 1-ch RCA, 8-ch via coaxial cable
- Audio Output: 1-ch RCA
- Supported Camera Types: HD TVI Input (3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p), AHD Input (5MP(20F), 4MP, 1080p, 720P), CVI Input (5MP(20F), 4MP, 1080p, 720P), CVBS Input, IP Video Input (6MP/5MP/4MP/3MP/1080P/720P)
- Analog HD Playback Resolution: 3K Lite/5MP Lite/4MP Lite@12fps, 1080p/720p@15fps
- IPC Playback Resolution: Up to 6MP
- Max Playback Channel: 8-ch
- Total Bandwidth: 96Mbps
- Remote Connection: 64
- HDD Capacity: Up to 10TB
- Dimensions (W x H x D): 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
- Weight (without hard disk): ≤ 1 kg (2.2 lb)
Camera
- Image Sensor: 2MP CMOS Image Sensor
- Video Resolution: 1920 (H) X 1080 (V)
- Lens: 2.8 mm
- Min. Illumination: 0.001 Lux@(F1.0, AGC On), 0 Lux with White Light
- Angle of View: horizontal FOV: 102°, vertical FOV: 54°, diagonal FOV: 121°
- Light Distance: Up to 65 ft/20 m
- Weatherproof Rating: IP66
- Dimensions: 82.65 mm × 91.0 mm × 69.16 mm (Ø 3.25" × 3.58" × 2.72")
- Weight: Approx. 238.5 g (0.53 lb)
Usage
- Remote monitoring via iPhone, iPad, and Android devices.
- Real-time push notifications and email alerts for suspicious movements.
- Bright white light alarm to deter intruders and enhance night visibility.
