General description
The ANNKE Smart Dual Light CCTV Kit includes 4 high-definition 5MP cameras designed for outdoor security. This advanced system features night vision capabilities, email alerts, and remote control via an app or PC, ensuring comprehensive surveillance for your property.Technical specifications
- Camera Sensor: 1/3" Progressive Scan CMOS
- Max Resolution: 3K (3072x1728) at 20fps
- Video Compression: H.265+/H.265/H.264+/H.264
- Video Output: HDMI up to 4K (4096 × 2160), VGA up to 1080p (1920 × 1080)
- Audio Input: Built-in Microphone
- Lens: 2.8 mm
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Angle of View: Horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°
- Supplement Light Range: Up to 30 m
- Operating Power: DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W
- Operating Temperature: -22 °F to 140 °F (-30 °C to 60 °C)
- Dimensions (L x W x H): 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7")
- Weight: 0.6 lb (270 g)
Compatibility and accessories
- Supports up to 8 IP cameras with PoE inputs
- Compatible with third-party network cameras
- Storage: Built-in microSD/SDHC/SDXC Slot, up to 512 GB
- Max HDD Capacity: Up to 8 TB
Installation
- Easy installation with PoE support
- Includes 8CH PoE NVR for seamless connectivity
Usage
- Remote monitoring via mobile app (iPhone, iPad, Android)
- Real-time audio and video recording
- Smart Dual-Light technology for enhanced night vision
- Motion detection with human and vehicle recognition
Other information
IP67 rated for weather resistance, capable of withstanding extreme conditions including heavy rain and snow.
