Automatic Transfer Switch (ATS) Single-Phase 63A AC220V Source Inverter with LED Display, Overvoltage and Undervoltage Protection for Mains Inverters and Generators (GPS8-17)

#1 in sales

Product information

Description

【Automatic Switching】: The automatic transfer switch (ATS) features overvoltage and undervoltage protection. It can connect two power sources and automatically switch between the primary and backup sources. In the event of a failure of the primary source (L1), the ATS automatically switches to the backup source (L2) to ensure continuous operation (switching time: 200 ms). 【Accurate Monitoring】: Equipped with a built-in voltage and current monitoring function, the automatic transfer switch displays the real-time voltage of the primary/backup sources as well as the load current. The LED indicators on the panel provide clear visual feedback on fault status and phase selection, allowing for intuitive monitoring of the device's operation. [Multiple Parameter Settings]: This dual-power switch (priority selection: L1-L2-Auto) is suitable for electrical systems with a rated current of 63A (45/65Hz). The switching time is adjustable from 0 to 900s (default: 0s, corresponding to a minimum actual switching time of approximately 200ms), and the reset time is adjustable from 2 to 900s (default: 10s). These settings offer flexibility to adapt to different equipment power requirements. [Easy Installation]: Thanks to its DIN rail mounting and compact size of 82*72*68 mm, this transfer switch takes up minimal space and can be installed in a standard household electrical panel. Its flame-retardant ABS housing makes it adaptable to complex environments, ensuring stable and reliable operation.
【Wide Range of Applications】: This automatic transfer switch effectively prevents equipment shutdowns due to power outages. It is suitable for various power supply needs, whether for home use, in small technical rooms, or for industrial control systems.

Parameters:

Function: Automatic transfer switch

Rated supply voltage: 220V AC (L1-N1, L2-N2)

Rated supply frequency: 45-65Hz

Operating voltage range: 80V-400V (L1-N1, L2-N2)

Rated operating current: 63A

Load: Max. AC 3VA

Overvoltage tripping value: OFF, 230V–300V (default: 275V)

Undervoltage tripping threshold: 140V–210V, OFF (default: 175V)

Overvoltage/undervoltage tripping delay: 0.1s–10s (default: 0.5s)

Overcurrent tripping threshold: 1A–63A

Overcurrent tripping delay: 2s–600s (default: 5 seconds)

Power-up delay: 2–600s (default: 5 seconds)

Reset time: 2–900s (default: 10 seconds)

Switching time: 0–900s (Default: 0 seconds; actual switching time approximately 200 ms minimum)

Fault Reset: On/Off (Default: On)

Power Priority: L1-L2-AUTO

Measurement Error: ≤1%

Electrical Life (AC1): 1×10⁴

Mechanical Life: 1×10⁶ cycles

Operating Temperature: -20°C to +60°C

Storage Temperature: -35°C to +75°C

Mounting/DIN Rail: DIN rail compliant with EN/IEC 60715

Protection Rating: Front panel IP40 / Terminals IP20

Package Includes:

1× Dual power switch

1× instruction manual (in English)

Features

Brand
COOCHEER
Colour
Black
IP rating
IP40
Nominal intensity
AC
Material
Acrylonitrile butadiene styrene (ABS)
Number of modules
1
Switch type
Modular switch
Type of connection
To crimp
Contact type
Normally closed
ManoMano Reference
ME102646996
MMID
521899782592
Product code
HD129C-260328389
