Chain Block And Tackle 10T 10M (Hoist Lifting Ton Metre)

Name: Chain Block And Tackle 10T 10M (Hoist Lifting Ton Metre)
Brand: SECUREFIX DIRECT
SKU: SFACECB1010
Price: 850 GBP
Availability: InStock

Sold by SecureFix Direct

Product information

Description

General description

Chain Block and Tackle with a safe working load of 10 tons (10,000 kg) and a lifting height of 10 metres. This hoist features four chain falls and is designed for efficient lifting and lowering of heavy loads. The construction includes a chain guide for smooth operation and a lightweight steel design for easy transport.

Technical specifications

Safe Working Load: 10 Ton (10,000 KG)

Lift Height: 10 Metres

Chain Falls: 4

Load Chain Diameter: 10 MM

Hand Chain Length: 9.7 Metres

Minimum Distance Between Hooks: 700 MM

Chain Block Height: 550 MM

Lower Hook & Bracket Length: 390 MM

Lower Hook/Top Hook Opening: 50 MM

Factor of Safety: 4:1

Other information

Conforms to: BS EN 13157: 2004+A1: 2009

Safety hooks are drop forged and heat treated for durability

Supplied with test certificate (sent via email)

Colour may vary; contact for black finish

Product Code: SFACECB1010

Features

Brand
SECUREFIX DIRECT
Maximum load
10000 kg
Supplied with hauling pulley
Yes
Height
55 cm
Work cable length
10 m
Material
Two-material
power supply
Manual
Hoist type
Manual
ManoMano Reference
ME27141443
MMID
981722637005
Product code
SFACECB1010
EAN
0600988501119

Advice from

Hoist buying guide

A hoist can be manual, electric, pneumatic or hydraulic. With the manual models, the hoist is composed chains and can include a lever. It allows to lift loads of 500 kg, 2 tons, 3 t or 5 t. The electric hoist offers more comfort and is often move on a trolley. It can efficiently lift and lower loads with precise accuracy.
