High-Speed Steel (HSS) Machine Tapping Tap for M20x2.5mm Threads, White Finish, 6H DORMER
Sold by GravaHaus and 3 other sellers
You may also like
Compare with similar items
Product information
Description
Description
The HSS hand tap NO2 is designed for cutting internal threads with a straight profile. It features a metric M20 thread with a 2.50 mm pitch and a 6H tolerance class. The tap has a cylindrical shank with a square drive measuring 11.2 mm and an overall length of 14 mm, complying with ISO 529 standards. Made from high-speed steel with a polished surface, it is suitable for creating both through and blind threads with a diameter 1.5 times D in construction steel and carbon steel. This tool is ideal for precise internal threading in various metalworking applications.
Technical Specifications
- Thread type: Internal, straight profile
- Thread size: M20 x 2.50 mm
- Tolerance class: 6H
- Material: High-speed steel (HSS)
- Surface finish: Polished
- Shank diameter: 14 mm
- Drive type: Square (11.2 mm)
- Overall length: 14 mm
- Thread length: 29 mm
- Cutting direction: Right-hand
- Applicable for through and blind holes
Compatibility and Accessories
- Compatible with standard tap wrenches and handles designed for square drives
Installation
- Insert the tap into a suitable tap wrench or handle with a matching square drive
- Secure the tap firmly to prevent slipping during threading
Usage
- Align the tap with the drilled hole
- Turn clockwise to cut internal threads, applying steady pressure
- Use cutting lubricant if necessary to improve thread quality and tool life
Features
- BrandDORMER
- Pcs per pack1
- Metric thread not standard threadM20
- Length29 mm
- Suitable forMineral / stone
Advice from
Taps and dies buying guide
Taps and dies are essential to make or re-thread a screw, a nut or any other mechanical element. The three-piece tap sets are the most commoly used and the tap wrench is as important as the die stock for a proper tapping. Drilling is required before tapping.
