Dormer E650M5 HSS Metric Coarse Combination Drill & Spiral Flute Tap M5 DORE650M5

Name: Dormer E650M5 HSS Metric Coarse Combination Drill & Spiral Flute Tap M5 DORE650M5
Brand: DORMER
SKU: E650M5
Price: 54.92 GBP
Availability: InStock

Sold by Trade Hut Direct and 4 other sellers

Product information

Description

General description

This is a high-quality combination drill with a spiral thread at a 30° angle, designed for precise threading and drilling tasks. It features a durable HSS (High-Speed Steel) construction with a vapor-hardened coating for enhanced longevity and performance. The drill is suitable for creating metric ISO M5 threads with a 0.80 mm pitch and can be used for through-hole threading in construction steel and other materials.

Technical specifications

Material: HSS (High-Speed Steel) with vapor-hardened coating

Cutting direction: Right-handed

Thread type: Metric ISO M5 with 0.80 mm pitch

Helix angle: 30°

Shank diameter: 5 mm

Square drive: 4 mm

Overall length: 69 mm

Number of flutes: 2

Tolerance class: 6H

Cutting edge length: 1.5 times the diameter

Thread length: 15 mm

Thread size: 5

Thread standard: Metric Coarse

Compatibility and accessories

Compatible with standard drill chucks and holders that accept 5 mm shank tools

Suitable for threading in steel, construction steel, and similar materials

Installation

Insert the shank into a compatible drill chuck or holder

Ensure the drill is set to rotate clockwise for right-handed threading

Use appropriate cutting speeds and lubrication for best results

Usage

Use for creating metric ISO M5 threads with a 0.80 mm pitch

Ideal for through-hole threading in construction steel and other metals

Apply steady pressure and maintain proper speed during operation

Other information

Dormer E650 5.00MM HSS Combined Tap & Drill

Features

Brand
DORMER
Pcs per pack
1
Certification body
ISO
Diameter
5 mm
Length
100 mm

Advice from

Taps and dies buying guide

Taps and dies are essential to make or re-thread a screw, a nut or any other mechanical element. The three-piece tap sets are the most commoly used and the tap wrench is as important as the die stock for a proper tapping. Drilling is required before tapping.
