Dormer E650M8 HSS Metric Coarse Combination Drill & Spiral Flute Tap M8 DORE650M8

Name: Dormer E650M8 HSS Metric Coarse Combination Drill & Spiral Flute Tap M8 DORE650M8
Brand: DORMER
SKU: E650M8
Price: 59.35 GBP
Availability: InStock

Sold by Trade Hut Direct and 4 other sellers

Product information

Description

General description

This is a high-quality combined threading drill bit designed for precise cutting in metalworking applications. The Dormer E650M8 HSS Metric Coarse Combination Drill & Spiral Flute Tap allows for drilling and threading holes in one single operation, featuring right-hand spiral grooves for creating internal threads with accuracy and durability.

Technical specifications

Size: M8

Tip Diameter: 6.8mm

Overall Length: 96mm

Shank Length: 9mm

Shank Diameter: 8mm

Square Size: 6.3mm

Cutting Direction: Right-hand

Coating: Vapor tempered

Shape: C 2 - 3

Tolerance Field: 6H

Number of Cuts: 2

Standard: DORMER-ISO

Cutting Material: HSS (High-Speed Steel)

Compatibility and accessories

Compatible with standard drill chucks that accept 8mm shanks

Suitable for use with compatible tapping and threading tools

Installation

Insert the shank into a compatible drill or tapping machine

Ensure the drill is set to rotate clockwise for right-hand threading

Secure the bit firmly before operation

Usage

Use in metalworking to create internal threads in metal parts

Operate at appropriate speeds for HSS tools to ensure precision and longevity

Apply suitable cutting fluid to reduce heat and wear during use

Features

Brand
DORMER
Diameter
8 mm
Weight
1000 g
Material
HSS
Suitable for
Metal
