Draper 12mm Outside Diameter Coarse Circular Die (Model 83813)

Description

• This is a 1-inch outside diameter circular die designed for threading applications. It is manufactured from high carbon steel for durability and precision. The die features coarse threads suitable for various threading tasks. It is supplied in a display pack for easy storage and handling.

Technical Specifications

• Diameter: 1 inch (12mm)
• Thread pitch: 1.75mm (M12 x 1.75)
• Material: High carbon steel
• Thread type: Coarse

Compatibility and Accessories

• Compatible with standard threading tools and holders for M12 x 1.75 threads
• Suitable for use in metalworking and DIY threading projects

Installation

• Insert the die into a compatible die holder or threading tool
• Align the die with the workpiece to ensure proper threading
• Apply steady pressure and turn clockwise to cut the thread

Usage

• Use for cutting external threads on metal rods or pipes
• Ensure the workpiece is securely clamped before threading
• Apply cutting oil to improve thread quality and tool life
