Draper 230V Belt and Disc Sander with 100mm Belt, 200mm Disc, 500W Power (Model 98525)

Name: Draper 230V Belt and Disc Sander with 100mm Belt, 200mm Disc, 500W Power (Model 98525)
Brand: DRAPER
SKU: BDS500D.
Price: 201.71 GBP
Availability: InStock

Sold by GravaHaus and 2 other sellers

Product information

Description

General description

This is a versatile belt and disc sander designed for woodworking and similar materials. It features a powerful 500W motor, providing efficient sanding performance. The machine includes a 100mm sanding belt that can be positioned horizontally or vertically from 0 to 90 degrees, and a 200mm diameter disc with its own worktable and mitre gauge. The disc worktable can pivot from 0 to 45 degrees for precise angle sanding. It is equipped with safety features such as a no-volt switch and dust extraction options, including a dust bag, clamp, and the ability to connect to a vacuum for enhanced dust removal. Supplied with sanding belt and disc for immediate use.

Technical specifications

Power: 500W

Voltage: 230V

No load speed (disc): 2850rpm

Belt speed: 9.2m/s

Belt size: 100 x 914mm

Disc diameter: 200mm

Disc table size: 150 x 264mm

Disc tilt: 0-45°

Belt tilt: 0-90°

Dimensions: 540 x 370 x 325mm

Weight: 21.5kg

Compatibility and accessories

Suitable for sanding wood, plastics, and similar materials

Supplied with sanding belt and disc

Can be connected to a vacuum for dust extraction

Installation

Designed for benchtop use in workshops or hobby areas

Ensure stable placement on a flat surface

Adjust the belt and disc angles as needed using the provided mechanisms

Usage

Use the belt and disc for shaping, smoothing, and finishing wood and plastics

Adjust the worktable angles for precise sanding tasks

Connect to a vacuum system for a cleaner work environment

Other information

The discs are easily changed through the ‘hoop & loop’ mechanism

The machine is designed and manufactured for sanding wood and similar materials and should not be used to abrade or grind metal

Features

Brand
DRAPER
Tilt angle
45 °
Disc / blade diameter
200 mm
Belt width
100 mm
Material
Metal
Weight
21.5 kg
Power
500 W
Tilting table
Yes
Sander type
Belt sander
Type of stationary sander
Belt and disc
ManoMano Reference
ME41625507
MMID
305835179160
Product code
BDS500D.
EAN
5010559985258
