EN24 For Audi A6 TT 1.8T BAM AEB High Performance Conrods Connecting Rod ARP2000









Application

Note: Please double confirm the dimensions before purchasing
No tappered Small End
For Audi / For VW Golf Gti 1.8T 2.0L 16V 20V 4 Cyl.
For Audi S3 A3 A4 A6 TT & For VW 1.8T Engines
----------
For Audi A3 1.8 20vT AGU/ARZ/ARX/AUM/AQA 1996–2003
For Audi S3 1.8 20vT APY AMK 1999–2001
For Audi S3 1.8 20vT BAM AEB 2001–2003
For Seat Ibiza 1.8T (AYP AQX)
For Audi A4/A6 1.8 20vT (AEB ANB APU ARK)
For Audi TT Quattro 1.8T BAM AEB
For VW Golf 1.8T (GTi AGU ARZ)
For VW Jetta, For VW New Beetle 2001–present
For VW Passat 1.8T (AEB ANB ATW)
For VW Beetle 1.8T (AVC)
For VW Bora 1.8T (AGU)







Specification

*Type: Forged 4340 aircraft chrome moly quality steel for racing
*H-beam Conrods Quantity: 4 Pieces as showing in picture
*Bolts: Including ARP 2000 3/8" bolts  (Note: Extra cost for upgrading to ARP L19 bolts)
*The connecting rods all include ARP 2000 bolts, which are rated at 220,000 psi, and the optional ARP L19 material at 260,000 psi is available as an upgraded product.
*Advertised Horsepower Rating:200HP/piece
*Top acceleration: 9000rpm
*package size：28CM*21CM*10CM







Dimension

Center to center length:144mm/5.669"
Big end diameter:50.6mm/1.992"
Small end diameter:20mm/0.787"
Big end width:24.9mm/0.98"
Small end width:24.9mm/0.98"





Feature

1. TÜV PRODUCT TEST AND TÜV ISO 9001 CERTIFIED；
2. Material: Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing；
3. ARP 2000 bolts ,Optional ARP L19 fasteners available as an upgrade；
4. H-Beam design reduces weight without compromising strength；
5.Heat-treating & Shot-peened for remained consistent and strong. Shot-peened finish to remove potential for stress risers；
6.High precision CNC machined,Precision rod cap alignment dowels；
7.Bores finished to +/- .01 mm；
8.Balanced to within +/- 1 g per rod；
9. Each rod is magnetic particle tested to ensure free of flaws；
10.Use X-rayed, sonic tested；
11.Custom Service.





NOTE

*There are titanium-plated upgrade models；
*Professional installation is highly recommended ；
*Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
