Extractor fan System Silent Escudo Beige 100 H

(£118.99/pc)

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by creoven

Product information

Description

General description

The Extractor Fan System Silent Escudo Beige 100 is designed for efficient ventilation in various settings. Its sleek beige front panel, made of durable ABS plastic, complements any decor while providing powerful airflow.

Technical specifications

Voltage: 220-240 V ~ 50 Hz

Nominal size: 100 mm

Speed levels: 1

Wattage: 5 W

Revolutions per minute: 1900

Max. airflow rate: 75 m³/h

Sound pressure level Lp-3m: 26 dB(A)

Total pressure Pmax.: 26 Pa

IP rating: IPX4

Max. ambient temperature: +40°C

Diameter pipe connection: 100 mm

Front cover dimensions: 160 x 160 x 30 mm

Total depth: 118 mm

Weight: 0.7 kg

Usage

The fan features an adjustable shut-off timer (3-30 min) and a humidity sensor (40-90%), allowing it to automatically turn off once the humidity level falls below the pre-set value. This makes it ideal for use in bathrooms, kitchens, or other areas prone to moisture.

Installation

The Extractor Fan can be mounted on walls or ceilings and is designed for direct connection to the ventilation shaft, ensuring easy installation and effective operation.

Features

Brand
AWENTA
Colour
Beige
Power
5 W
Power source
Corded
With timer
Yes
Max. flow rate
75 m³/h
Intended use
Indoor
Diameter
10 cm
Wall mounting possible
Yes
Height
16 cm
IP rating
IPX4
Material
Acrylonitrile butadiene styrene (ABS)
Operating Mode
Electric
Weight
0.7 kg
Noise level
26 dB
Fan type
Ceiling fan
ManoMano Reference
ME51228454
MMID
725825109017
Product code
1353206182
EAN
0745203005949
