General description
Whether it's day or night, our traditional wired bird box camera offers the easiest way to start observing wildlife in your garden. Just place it in your nest box, and the provided 3-way cable will send all the delightful bird activity straight to your TV. The camera features an enhanced IR filter with an infrared cut, allowing you to enjoy high-quality, true-to-life color images.Technical specifications
- Video Standard: PAL
- Image Sensor: OV7949/OV7950
- Vertical Resolution: 700 TV Lines
- Pixel Resolution: 512(H) x 582(V)
- Minimum Colour Illumination: 1 Lux
- Minimum B/W Illumination: 0 Lux (IR On)
- Lens: 2.8mm
- Viewing Angle: 110 degrees
- White Balance: Auto
- S/N Ratio: >48dB(AGC Off)
- Backlight Compensation: Auto
- Electronic Shutter: 1/50(1/60)-1/100,000 seconds
- Operation Temperature: -20 to 50 degrees C
- Power Supply: 12V DC <500mA
- Camera Dimensions: 44×44×33 mm
- Power Consumption: IR OFF = 1W IR ON = 1.2W
- Weight: 0.91 kg
Compatibility and accessories
- 12V Connection: Allows you to run power up to 50m and is compatible with all of our cables and accessories.
- All-In-One Cable: The cable carries video and power, which means you only need to install one cable between the camera and your house.
Installation
- Easy Mount Bracket: Use 1 x 5mm bolt to mount your camera with ease.
- Anti Twist Bracket Design: The Green Feathers anti twist bracket design prevents birds from knocking the camera when set up.
Usage
- Watch on your TV: To view live footage, simply connect the cable to your TV using the included cable.
- Robust Video: The camera produces interference-free images over the cable.
- Night Vision: Invisible infrared LEDs provide night vision for round-the-clock viewing, without disturbing the birds.
- Adjustable Focus Lens: Ensures sharp images, allowing you to see every feather and the sparkle in the bird's eyes.
