Name: Huepar LR-8RG Laser Receiver, Compatible with All Huepar and Pro Laser Levels, ±1/17 In, Up to 200Ft, Green & Red Beams Laser Detector, Two-Sided LED Prompt, Magnet, Clamp Included
Brand: HUEPAR
SKU: LR-8RG
Price: 59.99 GBP
Availability: InStock
Rating: 4.75 (4 reviews)

Product information

Description

General description

The Huepar LR-8RG Laser Receiver is an upgraded device compatible with all Huepar and Huepar Pro line laser levels that feature a pulse mode function. It allows for the detection of red and green pulse laser beams, making it ideal for use in challenging lighting conditions, with a working distance of up to 200 feet (60 meters) and an accuracy of ±1/17 inches.

Technical specifications

Pulse duration: 50 μs

PWM: 5:5

PRF Pulse Repetition Frequency: 10KHz

Display: Two-sided LED indicator

Accuracy: high accuracy ±1.5mm, low accuracy ±2mm

Working Distance: 60m (200ft)

Operating Time: 20 hours

Auto Power Off: 10 min

Power Source: 2 x AAA Batteries

Dimension (LxWxH): 5.6 x 2.7 x 1.5 inches

Mounting Thread: ¼”

IP rating: IP54

Beam colour detected: Green & Red

Up / Down / Level indicator: Yes

Audible Tone: 90dB

Compatibility and accessories

The LR-8RG is compatible with various Huepar laser levels that feature pulse mode, including:

BOX-1G

BOX-1R

HM03CG

GF360G

B03CG

S02CG

S03CG

S03CG-L

S04CG

S04CG-L

S03DG

S03DG-L

621CG

621CR

6211CG

7211CG

703CG

704CG

503CG

503DG

B02CG

B21CG

602CG

602CR

603CG

603CR

603CG-BT

901CG

902CG

904DG

8211G

LS03CG

LS03DG

LS04CG

NT411G

LS41G

L141G

L011G

P02CG

P03CG

P03DG

P04CG

R03CG

622CG

622CR

5011G

E011G

W04CG

W03CG

ZK03

ZK04

Installation

The receiver features a double-sided magnet, allowing for easy mounting on iron objects such as pipes or iron windows.

Usage

To ensure optimal performance, it is necessary to activate the pulse mode of the laser level when using it with the LR-8RG receiver. The device provides clear optical and acoustic signals to help locate the laser plane quickly and accurately, making it suitable for outdoor use.

Other information

The package includes:

1 x Huepar LR-8RG Laser Detector

1 x Holder

2 x AAAA Dry Batteries

1 x Instruction Manual

1 x Inner Box

Features

Brand
HUEPAR
Colour
Red / Green
Warranty
2 year(s)
Power source
Batteries
Height
3.8 cm
IP rating
IP54
Width
6.9 cm
Length
14 cm
Material
Acrylonitrile butadiene styrene (ABS)
Weight
400 g
Range
6096 cm
Type of accessories for measuring & detection tool
Reception cell
ManoMano Reference
ME94523942
MMID
316617458184
Product code
LR-8RG
EAN
5012663921467

Customer reviews

JJacques

Published on 17/08/2026, France

Good product and easy to use

PPATRICK

Published on 15/06/2026, France

Very good product. Works very well with the Huepar B03CG.

MManoMano Customer

Published on 10/03/2026, United Kingdom

Excellent product and the price was unbeatable
