Insulating Rubber Lined U-bolt and Backing pad 50 mm ID (suit 32 mm NB pipe)-T316 SS

Sold by Graphskill

You may also like

T304 Stainless Steel Munsen type bossed pipe clip M8 Boss - Pipe OD 12-15 mm

T304 Stainless Steel Munsen type bossed pipe clip M8 Boss - Pipe OD 12-15 mm

2
U-Bolt M6 x21mm Thread, 14mm Inside Diam, 35mm Inside Height T316 Stainless Steel

U-Bolt M6 x21mm Thread, 14mm Inside Diam, 35mm Inside Height T316 Stainless Steel

1
Insulating Rubber Lined U-bolt and Backing pad 36 mm ID (suit 25 mm NB pipe)-Galvanised

Insulating Rubber Lined U-bolt and Backing pad 36 mm ID (suit 25 mm NB pipe)-Galvanised

Light Duty Anti-Vibration Rubber Lined U-bolt 61 mm ID (suit 50 mm NB pipe) - BZP

Light Duty Anti-Vibration Rubber Lined U-bolt 61 mm ID (suit 50 mm NB pipe) - BZP

Pipe Saddle Clamp - Anchor - 50 mm ID, 46 mm IH, 30 x 3 mm T304 Stainless Steel (A2)

Pipe Saddle Clamp - Anchor - 50 mm ID, 46 mm IH, 30 x 3 mm T304 Stainless Steel (A2)

1
Low Friction Insulated U-Bolt and Backing Pad For Standard Schedule Pipe 36 mm ID (suit 25 mm NB pipe) - T316 Stainless Steel

Low Friction Insulated U-Bolt and Backing Pad For Standard Schedule Pipe 36 mm ID (suit 25 mm NB pipe) - T316 Stainless Steel

Pipe Saddle Clamp - Guide - 30 mm ID, 29 mm IH, 25 x 3 mm Steel Galvanised

Pipe Saddle Clamp - Guide - 30 mm ID, 29 mm IH, 25 x 3 mm Steel Galvanised

1
Pipe Saddle Clamp - Anchor - 34 mm ID, 32 mm IH, 25 x 3 mm Steel ZP (Zinc Plated)
#1 in sales

Pipe Saddle Clamp - Anchor - 34 mm ID, 32 mm IH, 25 x 3 mm Steel ZP (Zinc Plated)

2
Pipe Saddle Clamp - Anchor - 22 mm ID, 19 mm IH, 25 x 3 mm Galvanised Steel

Pipe Saddle Clamp - Anchor - 22 mm ID, 19 mm IH, 25 x 3 mm Galvanised Steel

1
Pipe Saddle Clamp - Anchor - 13 mm ID, 11 mm IH, 25 x 3 mm Steel Galvanised

Pipe Saddle Clamp - Anchor - 13 mm ID, 11 mm IH, 25 x 3 mm Steel Galvanised

Pipe Saddle Clamp - Anchor - 28 mm ID, 25 mm IH, 25 x 3 mm Galvanised Steel

Pipe Saddle Clamp - Anchor - 28 mm ID, 25 mm IH, 25 x 3 mm Galvanised Steel

1
Pipe Saddle Clamp - Guide - 38 mm ID, 35 mm IH, 25 x 3 mm Steel (ZP) Zinc Plated

Pipe Saddle Clamp - Guide - 38 mm ID, 35 mm IH, 25 x 3 mm Steel (ZP) Zinc Plated

1
Pipe Saddle Clamp - Anchor - 34 mm ID, 32 mm IH, 25 x 3 mm Galvanised Steel

Pipe Saddle Clamp - Anchor - 34 mm ID, 32 mm IH, 25 x 3 mm Galvanised Steel

U-Bolt M12 x40mm Thread, 90mm Inside Diam, 130mm Inside Height T304 Stainless Steel

U-Bolt M12 x40mm Thread, 90mm Inside Diam, 130mm Inside Height T304 Stainless Steel

U-Bolt M12 x40mm Thread, 170mm Inside Diam, 210mm Inside Height T304 Stainless Steel

U-Bolt M12 x40mm Thread, 170mm Inside Diam, 210mm Inside Height T304 Stainless Steel

U-Bolt M16 x105mm Thread, 100mm Inside Diam, 185mm Inside Height T316 Stainless Steel

U-Bolt M16 x105mm Thread, 100mm Inside Diam, 185mm Inside Height T316 Stainless Steel

U-Bolt M12 x40mm Thread, 140mm Inside Diam, 180mm Inside Height Galvanised

U-Bolt M12 x40mm Thread, 140mm Inside Diam, 180mm Inside Height Galvanised

Pipe Saddle Clamp - Anchor - 50 mm ID, 47 mm IH, 40 x 8 mm T304 Stainless Steel (A2)

Pipe Saddle Clamp - Anchor - 50 mm ID, 47 mm IH, 40 x 8 mm T304 Stainless Steel (A2)

Insulating Rubber Lined U-bolt and Backing pad 29 mm ID (suit 20 mm NB pipe) - Zinc Plated Mild Steel

Insulating Rubber Lined U-bolt and Backing pad 29 mm ID (suit 20 mm NB pipe) - Zinc Plated Mild Steel

1
U-Bolt for 40 NB (48.3 OD) pipe. T316 Stainless Steel With Convex Base to Minimise Crevice Corrosion

U-Bolt for 40 NB (48.3 OD) pipe. T316 Stainless Steel With Convex Base to Minimise Crevice Corrosion

Compare with similar items

Product information

Description

General description

Insulating Rubber Lined U-bolt and Backing pad designed for 50 mm ID, suitable for 32 mm NB pipe. This product is ideal for preventing galvanic corrosion caused by the contact of dissimilar metals in the presence of an electrolyte, as well as for minimizing wear and crushing of composite, thin wall, or non-ferrous pipework.

Technical specifications

  • Pad Material: Neoprene Rubber
  • Elastomer: Neoprene
  • Colour: Black
  • Quality: Commercial
  • Grade: C20
  • Hardness: 65 shore A +/-5
  • Specific Gravity: 1.4 G/Cm3
  • Tensile Strength: 5 MPA (minimum)
  • Elongation: 300%
  • Tear Strength: 20 Kg/CM
  • Compression Set: 35%
  • Operating Temperature: -20 to +110 °C
  • Sleeve: 300 psi Black Air Hose (ISO2398)
  • Tube Material: Black NBR/SBR synthetic rubber
  • Reinforcement: Synthetic textile
  • Cover Material: Black, weather and ozone resistant SBR/EDPM
  • Temperature Range: -20 to +90 °C
  • U-Bolt Material: T316 Stainless Steel
  • Pipe O/D: 42.4 mm
  • Dimensions: A = 50 mm, B = 69 mm, C = 95 mm, D = 10 mm, E = 70 mm, F = 80 mm, G = 21 mm, D*A (backing pad) = 25*10 mm
  • Tolerance on dimensions: +/- 1 mm
  • Includes: 2 nuts on each leg

    • Other information

  • Not suitable for resistance to aliphatic and aromatic hydrocarbons and ketones.
  • Also available in zinc plated or galvanised on request.
  • Please note that as we use roll threading, the bar diameter is slightly less than the thread diameter.

    • Features

    • Brand
      GRAPHSKILL
    • Width
      5 cm
    • Material
      Stainless steel
    • Certification body
      ISO
    • Pipe clamp use
      Hose clamp
