Linear Guide Rail Set

The listing is for supported linear rails SBR20-300/600/1000 mm rails (6 supported rails+12 SBR20UU bearing blocks), 3pcs of ballscrews RM1605-350/650/1050 mm-C7 (3 screws + 3 ball nuts + 3 end-machinings ), 3 sets of BK/BF12 (with locknuts and cir-clips) and 3pcs of flexible couplings. Move smoothly without deflection, minimal wear, and low noise.

Complete Linear Rail Kits
High-Quality Steel Material
Premier Linear Guiding System
Easy to Install

Key Features

Complete Linear Rail Kits: This set includes supported linear rails SBR20-300/600/1000 mm rails, two for each type, 3pcs of ball screws RM1605-350/650/1050 mm-C7, 3 sets of BK/BF12, and 3pcs of couplings 6.35 mm*10 mm.
High-Quality Steel Material: Linear guides are made of quality material. The ball screw with high efficiency and low heat generation can ensure accurate micro feed and get a higher rigidity.
Premier Linear Guiding System: Complete sliding unit's system with high accuracy and can be moved without deflection. There is a lot of ball rolling motion between the screw shaft and nut. Therefore, it is possible to obtain a high efficiency of movement.
Easy to Install: Quality support rail with pre-drilled holes for ease of mounting. The ball screw movement achieves high-speed feed. Convenient to install it, less effort to maintain.
Wide Application: The linear guide rail is widely used in CNC Router / CNC Grinding machines, industrial machinery printing, paper-processing, automatic machine, X-Y table, factory automation equipment, etc.


Fine Workmanship Linear slide kit includes 6pcs of linear rails, 3pcs of balls crews, 12pcs of blocks, 3 sets of BF/BK 12 supports, and 3pcs of flexible couplings. This bearing rail is constructed with a quality main axle, which makes it has a long service life.	Heavy-Duty Material These linear rails and ballscrews are made of high hardness steel material. The rust-proof and antioxidant surface treatment provide smooth running. What's more, the heatproof bearing steel blocks can work at high temperature and has very little friction.	Complete Linear Guiding System The complete sliding unit's system with a beautiful and anti-rust surface treatment makes your process move without deflection. The four-row arc groove design has high rigidity and strong bearing capacity.

Simple Installation The linear rail set prefers careful installation that, however, is easy. Then, after three steps, it is ready to run for a long time.	Quiet Operation Our professional and technical linear slides and blocks can stabilize the original rail. As a result, move smoothly without deflection, minimal wear, and low noise while using.	Extensive Application The linear rail and ball screw kit is widely used in automation machinery such as DIY CNC routers, lathes, machine tools, bending machines, laser welding machines, etc. Also applicable for large-scale transmission equipment, including industrial robots, cracker machines.
