Vacuum Pump 50 L/min with 2-way Manifold Gauge Set in Tool Kit vidaXL

This vacuum pump is designed for professional use in refrigeration and air conditioning systems.

The pump creates a vacuum, which makes the subsequent filling of the air conditioning system with refrigerant possible. Thanks to its technical characteristics, the pump is suitable for refrigeration repair, printing machinery, medical appliances, vacuum packaging, hot forming and other extraction operations. The pump features an aluminium housing and a practical oil sight glass, which allows you to check the oil level at any time. It also has an integrated handle for easy transport. This included 2-way manifold gauge set is suitable for filling and inspecting air conditioning systems by providing system pressure readings. It is suitable for use on all car A/Cs, as well as commercial and domestic A/C refrigeration systems. The colour-coded gauges are quick, clear and easy to read. The gauges are encased in a protective bumper to prevent damage. You can use the integrated steel hook to quickly and easily suspend the gauges. The manifold gauge set has a durable construction, and is supplied in a blow-moulded carrying case for easy transport and storage.

• Vacuum pump:
• Voltage: 220 V, 50 Hz
• Pump speed: 2.5 CFM
• Motor power: 1 / 3 HP
• Rotating speed: 2800 rpm
• Oil capacity: 250 ml
• Power: 250 W
• Suction power: 50 L / min
• Aluminium alloy housing
• 2-way manifold gauge set
• Hose length: 152 cm
• Burst pressure: 2500 PSI
• Maximum operating pressure: 500 PSI
• Bronze filling valve
• With 3 filling hoses
• With steel suspension hook
• With 2 quick connectors with adapters for use in car air conditioners
• Sight glass for controlling the flow of the refrigerant
• Suitable for refrigerants R134a, R22, R12 and R502
• Supplied in a blow-moulded carrying case
• Assembly required: Yes
• Delivery includes:
• 1 x Vacuum pump
• 2 x Oil bottle
• 1 x Connector
• 1 x 2-way manifold gauge set
• 1 x Tool kit

• SKU: 3100286
