General description
Modular Hydraulic Pressure Regulator Relief Valve CETOP3/NG6 is designed to regulate the maximum pressure within the operating parameters of winches or other controlled items. It is installed between the manifold block and directional control valve, allowing for pressure bypass to T when the set pressure is exceeded.Technical specifications
- Pressure adjustment range: 3.5 - 14 MPa (35 - 140 bar)
- Maximum flow rate: 35 l/min
- Weight: 1.5 kg
- Hydraulic fluid: Mineral oil
- Seal material: NBR seals
- Temperature range: -30 to +80 °C
- Viscosity range: 2.8 to 500 mm²/s
- Oil cleanliness class according to ISO 4406: Class 20/18/15
Compatibility and accessories
- Supplied with extended bolts for attachment between directional valve and manifold block
Usage
- Easy to operate rotary calibration control with lock ring
- Regulates maximum pressure for winches and other hydraulic systems
Other information
