X1 3/8" Painted Open Wedge Socket With Bolt And Pin - Grip Tail Wire Rope

Name: X1 3/8" Painted Open Wedge Socket With Bolt And Pin - Grip Tail Wire Rope
Brand: SECUREFIX DIRECT
SKU: SFWS10
Price: 20 GBP
Availability: InStock

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by SecureFix Direct

Product information

Description

General description

These Open Wedge Sockets with bolt and pin are designed for gripping wire rope across a variety of applications. They retain the rope's full strength while securely holding it in place, making them versatile for numerous uses.

Technical specifications

Size: 3/8"
Product Code: SFWS10 - Breaking Load: 8 Ton (A: 11.9 MM, B: 6.8 MM, C: 75 MM, D: 140 MM, E: 20.7 MM, F: 20 MM, G: 21.7 MM, H: 13.5 MM)
Product Code: SFWS13 - Breaking Load: 10 Ton (A: 14.5 MM, B: 9 MM, C: 104.8 MM, D: 180 MM, E: 26.2 MM, F: 25 MM, G: 25.7 MM, H: 15.7 MM)
Product Code: SFWS16 - Breaking Load: 20 Ton (A: 18.2 MM, B: 12 MM, C: 123 MM, D: 210 MM, E: 30.6 MM, F: 30 MM, G: 32.5 MM, H: 13.6 MM)
Product Code: SFWS20 - Breaking Load: 25 Ton (A: 21.8 MM, B: 12.9 MM, C: 148 MM, D: 250 MM, E: 35 MM, F: 35 MM, G: 37.5 MM, H: 17 MM)
Product Code: SFWS22 - Breaking Load: 50 Ton (A: 25.3 MM, B: 13.8 MM, C: 167 MM, D: 292 MM, E: 32.5 MM, F: 41 MM, G: 44.3 MM, H: 20.5 MM)
Product Code: SFWS26 - Breaking Load: 50 Ton (A: 29.6 MM, B: 19.8 MM, C: 192 MM, D: 320 MM, E: 49.9 MM, F: 50 MM, G: 51 MM, H: 22.8 MM)
Product Code: SFWS28 - Breaking Load: 60 Ton (A: 29.4 MM, B: 22.5 MM, C: 200 MM, D: 365 MM, E: 55 MM, F: 55 MM, G: 61.2 MM, H: 24.6 MM)
Product Code: SFWS32 - Breaking Load: 60 Ton (A: 34.1 MM, B: 25.9 MM, C: 220 MM, D: 405 MM, E: 63.8 MM, F: 65 MM, G: 64.1 MM, H: 29.5 MM)
