The function of a pool pump is to circulate water in the pipe network of your swimming pool. It draws in water from the pool basin via the skimmers and drain opening, passes it through a filter and in some cases a disinfection system, then releases the water into the basin via discharge nozzles. This procedure has the effect of purifying the water and removing suspended particles.Depending on your setup, a pool pump can also be used to operate a pool robot or release bubbles via massage nozzles.It is also essential for washing and rinsing the pool filter.The pump is typically the only mechanical element of a home swimming pool installation.As a result it's the part of your pool that's most likely to go wrong. And when we say go wrong, we mean filtration failure and cloudy, dirty pool water in no time...
Three essential criteria should be considered when working out what you need from your pool pump:
The flow rate you require will depend on the characteristics of your pool.To preserve an adequate quality of water, the filtration cycle must be capable of processing and filtering all the water in the pool in under six hours, four being optimum.Example: for a rectangular pool 8m x 4m in size, with an average depth of 1.5 m, pool volume is 48m3; so you want a pump flow of at least (48 / 4 =) 12m3/h to enable complete recycling of the water within four hours.However, this is a minimum, and it's always better to oversize your pump capacity. Without launching into a crash course in hydraulics, let's just say that water circulation can encounter various forms of resistance; so a good rule of thumb is to oversize the rated flow of your pump by a factor of 1.2 to 1.5.
Various specific factors may warrant additional pump capacity:
In our case, for a pool basin with a machine room slightly above the level of the pool and 8m away horizontally, a pump with a minimum flow of 15m3/h will be ideal.
If you really want to get into the nuts and bolts, refer to the manufacturer's charts provided with the pump which give flow figures according to system pressure. This will allow you to make precise comparisons between different models of pump, but short of having a very sophisticated installation, the simple methods of calculation mentioned above will do just as well.
Just look at the label on your pump or, failing that, at the user manual!The flow rate given on the pump corresponds to a certain pressure in the circuit - and this is where you need to be careful.The flow rate we calculated above is for pressure between 0.8 and 1 bar. If the flow rate given by the manufacturer corresponds to a lower pressure value, actual flow will be lower at 0.8 bar (since the pump will effectively be pushing against more resistance). You'll therefore need a more powerful pump to achieve a sufficient rate of water circulation.Other indications to be taken into account are the pump's operating voltage and power rating.Operating voltage will be a standard mains value (i.e. 230V in the UK), but you still need to establish whether your pump runs on single-phase or three-phase electricity. The choice here will depend on your existing domestic electricity network. The power rating (P) gives you an idea of energy consumption.Flow and power are related; for a given flow rate, a more powerful pump will last longer before it shows signs of wear.
A variable speed pump, as the name implies, allows the operating speed to be adjusted and in some cases pre-programmed according to your needs. This determines flow rate.If your pool is large in volume, it requires substantial filtration and its level of use varies widely, a variable speed pool pump is a good option. The same goes if you continue to use it during the winter.However, the price difference is hard to justify given the limited savings in energy consumption.
The price range of pool pumps is wide, the most expensive being the variable speed models.Keep in mind that your choice will depend heavily on the size and format of your pool... A small above-ground pool won't need as robust a pump as a large inground pool.
For pools that are only in use during a short window of time, a fairly basic model of pump should suffice. On the other hand, if your pump is expected to run all year round to serve a heated pool, you'll need a more reliable, higher-end model.
In any case, choosing a self-priming pump equipped with a pre-filter will give you a longer lifespan.
If you use salt as a disinfectant in your pool (or indeed if it's a salt water pool), check that your pump is compatible with salt water.
Finally, noise level (measured in decibels, dB) can be an important factor when making your choice if your pump is installed near the pool or in an area used for other activities.
