General description
The ANNKE 12MP Outdoor Security Camera Kit includes a powerful 32-channel NVR and advanced surveillance cameras designed for high-quality monitoring. With features like smart dual light night vision, motion detection, and remote access via app or PC, this kit ensures comprehensive security for your property.Technical specifications
- Camera Resolution: 12 MP
- NVR Incoming Bandwidth: 256 Mbps
- Video Compression: H.265+/H.265/H.264+/H.264/MPEG4
- Video Output: HDMI up to 4K (3840 × 2160), VGA up to 1080p
- Max Recording Resolution: Up to 12 MP
- Max Playback Resolution: Up to 12 MP
- Max Playback Capacity: 2CH @12MP (20 fps), 4CH @8MP (25 fps), 8CH @4MP (30 fps), 16CH @1080p (30 fps)
- Camera Lens: 2.8 mm
- Field of View: Horizontal 113°, Vertical 62°, Diagonal 134°
- Minimum Illumination: Color: 0.005 Lux, B/W: 0 Lux with IR
- Operating Power: DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W
- Operating Temperature: -22 °F to 140 °F (-30 °C to 60 °C)
- Dimensions (Camera): Ø110 mm × 93 mm (Ø4.33" × 3.66")
- Weight (Camera): 0.6 lb (285 g)
- NVR Dimensions: 17.5" X 15.7" X 2.8" (445 mm X 400 mm X 71 mm)
- NVR Weight: ≤11 lbs (5 kg)
Compatibility and accessories
- Supports up to 32 IP cameras
- 4 SATA interfaces for hard drives, supporting up to 12 TB each (48 TB total)
- Built-in microSD/SDHC/SDXC slot, up to 512 GB
Installation
- Easy installation with PoE support for simplified wiring
- Includes 16 PoE ports for direct camera connection
Usage
- Remote access via mobile app or PC for real-time monitoring
- Smart motion detection with human and vehicle recognition to reduce false alerts
- Audio recording capability with built-in microphone
