General description
The ANNKE 5MP 16CH Outdoor Security Camera System is a comprehensive surveillance solution featuring 8 IP cameras equipped with advanced technology for enhanced security. This system supports two-way audio, IR night vision, smart motion detection, and email alerts, allowing for real-time monitoring and communication. With a robust design suitable for outdoor use, it ensures reliable performance in various weather conditions.Technical specifications
- NVR: Supports up to 16 IP cameras with PoE inputs
- Video Compression: H.265+/H.265/H.264+/H.264
- Max Recording Resolution: Up to 12MP (4096 x 3072) at 30fps
- Video Output: HDMI up to 4K (3840 x 2160), VGA up to 1080p
- Audio Input/Output: 1/1 RCA
- Operating Power: AC 100-240 V
- Power Consumption: ≤15 W (without HDD and PoE)
- Working Temperature: 14 °F — 131 °F (-10 °C — 55 °C)
- Dimensions (W x H x D): 15.2” x 12.4” x 2.0” (385 x 315 x 52 mm)
- Weight (without hard disk): 6.6 lbs (3 kg)
- Camera: 1/3" Progressive Scan CMOS, Max Resolution: 3K (3072 x 1728)
- Lens: 2.8 mm
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Angle of View: Horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°
- IP Rating: IP67 (weatherproof)
- Weight: Approx. 340 g (0.7 lb)
Compatibility and accessories
- Supports up to 512 GB microSD/SDHC/SDXC for local storage
- Compatible with third-party IP cameras
Installation
- Easy installation with PoE support for simplified wiring
- Includes mounting hardware for secure placement
Usage
- Ideal for home and business security
- Real-time monitoring via mobile app (iPhone, iPad, Android) and PC
- Two-way audio allows communication through the camera
- Smart motion detection reduces false alerts by distinguishing between humans and vehicles
