General description
The ANNKE 5MP Outdoor CCTV Kit is a comprehensive security solution featuring an 8-channel NVR and eight smart dual-light cameras. This system offers advanced night vision capabilities, two-way audio, and motion detection, ensuring robust surveillance for your property. With remote access via mobile apps and PC, you can monitor your premises from anywhere.Technical specifications
- Camera Sensor: 1/3" Progressive Scan CMOS
- Max Resolution: 3K (3072*1728) at 20 fps
- Video Compression: H.265+/H.265/H.264+/H.264
- Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Lens: 2.8 mm
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Angle of View: Horizontal FOV 98°, Vertical FOV 54°, Diagonal FOV 114°
- Supplement Light Range: IR up to 30 m, White Light up to 20 m
- Operating Power: DC 12 V± 25%, max. 7.5 W; PoE (802.3af), max. 9 W
- Operating Temperature: -22 °F to 140 °F (-30 °C to 60 °C)
- Dimension (L X W X H): Ø 110 mm × 102.7 mm (Ø 4.33" × 4.04")
- Weight: Approx. 340 g (0.7 lb.)
- NVR Max Recording Resolution: Up to 12MP (4096 X 3072)@30fps
- NVR Dimensions: 315 mm x 240 mm x 48 mm (12.4” x 9.4” x 1.9”)
- NVR Weight: 1 kg (2.2 lbs) without hard disk
Compatibility and accessories
- Supports up to 8 IP cameras with PoE inputs
- Compatible with third-party network cameras
- Built-in microSD/SDHC/SDXC slot, supports up to 512 GB
- HDD capacity up to 8 TB
Installation
- Easy installation with PoE technology, eliminating the need for separate power cables
- Mounting hardware included for secure camera placement
Usage
- Ideal for outdoor surveillance with IP67 weatherproof rating
- Real-time security monitoring with two-way audio
- Remote viewing and control via mobile app (iPhone, iPad, Android) and PC
- Smart motion detection with human and vehicle recognition
