Name: Bristan Regency Thermostatic Shower Round Exposed Dual Control Mini Valve & Head
Brand: BRISTAN
SKU: R2 SHXAR C
Price: 248.63 GBP
Availability: InStock
Rating: 4 (1 reviews)

Product information

Description

General description

This Bristan Traditional Dual Control Monarch Mixer Shower Valve is designed for easy installation and retrofitting, making it an ideal replacement for various traditional shower valves, including the Bristan Colonial and Regency models. With adjustable pipe centres ranging from 110mm to 155mm, this valve allows for seamless integration with existing plumbing without the need for retiling. The elegant chrome finish and traditional design enhance any bathroom decor.

Technical specifications

Dimensions: 18cm x 14cm x 71cm

Adjustable distance between inlet centres: 110mm to 155mm

Inlet connection size: 15mm

Outlet connection: G 1/2 inch

Flow rate at 1.0 Bar: 19.6 l/min (Valve Only), 4.9 l/min (Through Handset)

Flow rate at 2.0 Bar: 27.8 l/min (Valve Only), 6.9 l/min (Through Handset)

Flow rate at 3.0 Bar: 34 l/min (Valve Only), 8.5 l/min (Through Handset)

Flow rate at 4.0 Bar: 39.3 l/min (Valve Only), 9.8 l/min (Through Handset)

Flow rate at 5.0 Bar: 43.9 l/min (Valve Only), 11 l/min (Through Handset)

Minimum pressure: 1.0 Bar

Maximum pressure: 5.0 Bar

Thermostatic cartridge maintains temperature to +/- 1°C

Factory set maximum temperature: 43°C (adjustable)

Compatibility and accessories

Supplied with adjustable riser kit

Includes 1.5m shower hose, riser rail, hose retainer, and single function handset

Comes with two sets of elbows for various inlet configurations: 2 x small elbows (110-130mm), 2 x large elbows (136-155mm), and 1 small elbow / 1 large elbow (125-145mm)

Installation

Easy installation with adjustable elbow inlets

Can be fed from top, bottom, or rear

Compatible with existing pipework centres between 110mm and 155mm

Usage

Dual control for separate flow and temperature adjustment

Ideal for family use with safety features like automatic shut-off during water supply failure

Maintains a constant temperature, compensating for changes in incoming water supply

Other information

TMV2 thermostatic control for enhanced performance

5-year guarantee including parts (1 year on labour)

Elegant traditional design with chrome plating to BS EN 248

Matching taps available

Water label: less than 7.6L/Min

Working water pressure: 0.1-bar to 5.0-bar

Model Number: R2-SHXAR-C

EAN Barcode: 5014868020976

Features

Brand
BRISTAN
Colour
Grey
Material
Brass
Origin
Made in China
Finishing appearance
Mirror-polished
Intended use of the tap
Shower
Hand shower included
Yes
Pipe thread size
1/2" (15x21)
Output thread
1/2" (15x21)
Shape
Rounded
Temperature limiter
Yes
Tap activation mechanism
Mechanical
Thermostatic mixer
Yes
Number of outlets
1
Weight
10 kg
Pcs per pack
1
Wall-mounted tap
Yes
Type de perçage
Two holes
Type of installation method
For mounting
Tap type
Dual-lever mixer
Installation type
Wall mounted
Mounting method
To screw
ManoMano Reference
ME10778641
MMID
881032482701
Product code
R2 SHXAR C
EAN
5014868020976

Bristan Regency Thermostatic Shower Round Exposed Dual Control Mini Valve & Head
