Draper Digital Multimeter 92433 with Auto and Manual Ranging for Precise Electrical Measurements

Name: Draper Digital Multimeter 92433 with Auto and Manual Ranging for Precise Electrical Measurements
Brand: DRAPER TOOLS
SKU: 92433
Price: 45.88 GBP
Availability: InStock

Sold by GravaHaus and 2 other sellers

Product information

Description

General description

This auto-ranging CAT IV digital multimeter is designed for precise electrical measurements in various industrial and automotive applications. It features a high-performance MCU processor for accurate readings and offers a wide range of functions including DC and AC voltage, current, resistance, capacitance, frequency, duty cycle, and diode testing. The multimeter is equipped with a large backlit LCD display, a non-contact voltage (NCV) sensor, and an inspection light for ease of use in different environments. It is suitable for electricians, maintenance engineers, construction workers, and electric vehicle technicians working on hybrid and electric vehicles.

Technical specifications

AC Current: 60μA/600μA/6mA/60mA/600mA/20A

AC Voltage: 600mV/6V/60V/600V/750V

DC Current: 60μA/600μA/6mA/60mA/600mA/20A

DC Voltage: 600mV/6V/60V/600V/1000V

Resistance: 6kΩ/60kΩ/600kΩ/6MΩ/60MΩ

Capacitance: 9.999nF to 99.99μF (multiple ranges)

Frequency: 9.999Hz to 9.999MHz

Temperature Range: -20°C to 1000°C (-4°F to 1832°F)

Dimensions: approximately 190mm x 90mm x 50mm

Weight: approximately 380g

Power: 9V battery (included)

Compatibility and accessories

Includes CAT IV 600V and CAT III 1000V probes

Supplied with a carry case

Probe storage bump cover

Magnetic hang strap

Temperature probe

9V battery

Installation

Insert the 9V battery into the designated compartment before first use

Connect the appropriate test leads or probes for your measurement

Usage

Capable of measuring DC voltage, AC voltage sine RMS, DC current, AC current sine RMS, resistance, capacitance, frequency, duty ratio, and diode on/off test

Features symbol unit data hold and automatic power-off functions

Features

Brand
DRAPER TOOLS
Warranty
1 year(s)
Shockproof
No
Battery or cell included
Yes
Measured function(s)
Diode / Resistance / Frequency / Capacitance
