General description
The VCN 160 external wall centrifugal fan is designed for efficient air extraction in residential, commercial, or industrial settings. With a powerful airflow rate of up to 650 m³/h, this fan ensures optimal ventilation and air circulation.
Technical specifications
- Voltage: 230 V ~ 50 Hz
- Max. wattage: 95 W
- Max. current consumption: 0.41 A
- Max. revolutions per minute: 2440
- Max. airflow rate: 650 m³/h
- Sound pressure level Lp-3m: 60 dB(A)
- Max. temperature for continuous operation: 55°C
- IP code: IPX4
- Weight: 4.53 kg
- Nominal width: 160 mm
- Housing material: powder-coated steel
- Housing colour: blue
- Thermal overload protection
- Protective grille against birds and rodents
Compatibility and accessories
This fan is suitable for installation on external walls and is compatible with various ventilation systems.
Installation
Designed for easy installation, the VCN 160 can be mounted directly onto external walls, ensuring a secure fit for effective air extraction.
Usage
The VCN 160 is ideal for use in:
- Residential buildings
- Commercial spaces
- Industrial environments
Other information
| Ø D (mm) | B (mm) | H (mm) | L (mm) | |
|---|---|---|---|---|
| VCN 160 | 159 | 300 | 400 | 138.2 |
