Extractor fan Orbit 150 F

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by creoven

Product information

Description

General description

The Orbit 150 Extractor Fan is designed for efficient ventilation in various settings. It features a sleek white housing made from UV-resistant ABS, ensuring durability and longevity. With its adjustable shut-off timer and light sensor, this fan operates automatically based on light detection, making it a convenient choice for any space.

Technical specifications

Voltage: 220-240 V ~ 50 Hz

Wattage: 18 W

Speed levels: 1

Revolutions per minute: 2400

Airflow rate: 210 m³/h

Sound pressure level Lp-3m: 46 dB(A)

Total pressure Pmax.: 44 Pa

IP rating: IPX4

Max. ambient temperature: +40°C

Diameter front cover: 210 mm

Diameter pipe connection: 150 mm

Length pipe connection: 83 mm

Total length: 120 mm

Weight: 0.9 kg

Installation

Mounting options: ceiling or wall

Application: direct connection to the ventilation shaft

Features

Brand
AWENTA
Colour
White
Shape
Cylindrical
IP rating
IPX4
Material
Acrylonitrile butadiene styrene (ABS)
Air flow
210 m³/h
Aerator control type
Switch
With timer
Yes
Integrated non-return valve
Yes
Presence detector
Yes
Height
12 cm
Weight
900 g
Depth
12 cm
Power
18 W
Noise level
46 dB
Pcs per pack
1
Ball bearings
Yes
Type of lawn aerator
Classic
ManoMano Reference
ME51228444
MMID
393832023295
Product code
WXO150F
EAN
5905033305892
