Grade 80 Omega Link 7MM Lifting Chain (2 Ton Coupling Link Connector 2T)

Name: Grade 80 Omega Link 7MM Lifting Chain (2 Ton Coupling Link Connector 2T)
Brand: SECUREFIX DIRECT
SKU: SFYASCL07
Price: 7.15 GBP
Availability: InStock

Sold by SecureFix Direct

Product information

Description

General description

This Grade 80 Omega Link 7MM Lifting Chain is a high-quality coupling link designed for the lifting gear industry. It is primarily used as a connector between equipment in conjunction with flat master links. The chain is made from Grade 80 material and is available in a yellow color, although the color may vary.

Technical specifications

Material: Grade 80

Chain Size: 7MM

Safe Working Load (SWL): 2 Ton

Factor of Safety: 4:1

Conforms to: BS EN 1677

Dimensions:

A (MM): 11.5

B (MM): 49

C (MM): 10.5

D (MM): 22

E (MM): 52

F (MM): 69

G (MM): 9

H (MM): 33.5

Other information

Test Certificate will be supplied via email

Free delivery available

Features

Brand
SECUREFIX DIRECT
Diameter
7 mm
Weight
100 g
Material
Two-material
Pcs per pack
1
