Nuie Sanford Thermostatic Concealed Shower Valve Triple Handle - Chrome

Name: Nuie Sanford Thermostatic Concealed Shower Valve Triple Handle - Chrome
Brand: NUIE
SKU: SANTR02
Price: 193.95 GBP
Availability: InStock

Sold by Heat & Plumb

Product information

Description

General description

The Nuie Sanford Thermostatic Concealed Shower Valve features a minimalist and sleek design, suitable for both vertical and horizontal installation. This modern rectangular valve is crafted from high-quality brass and ABS, ensuring durability and a stylish appearance. It supplies water to two outlets and offers accurate flow control with thermostatic regulation, maintaining temperature within +/- 2 degrees even during pressure fluctuations.

Technical specifications

Shower Type: Thermostatic Shower Valve

Controls: 3

Valve Position: Concealed

Valve Shape: Rectangular

Handle Type: Lever/Square

Shower Valve Outlets: 2

Minimum Pressure: 0.1 Bar

Shower Valve Height: 300mm

Shower Valve Width: 80mm

Shower Valve Depth: 72-85mm

Inlet Connection Size: 1/2 BSP

Outlet Connection Size: 1/2 BSP

Material: Brass/ABS

Colour: Chrome

Weight: 3.45 Kg

Flow Rate @ 0.1 Bar: 5.5 l/min

Flow Rate @ 0.5 Bar: 14 l/min

Flow Rate @ 1.0 Bar: 20 l/min

Flow Rate @ 2.0 Bar: 29 l/min

Flow Rate @ 3.0 Bar: 44 l/min

WRAS Approval Number: 1703023

Manufacturer Part Number: SANTR02

EAN Barcode: 5056211898115

Compatibility and accessories

Suitable for all systems: gravity fed, pumped, unvented high pressure, or fully modulated combi-boilers

Cartridge is fully reversible for easy installation

Installation

Extra care must be taken during installation to avoid damaging the fittings

Usage

Thermostatic control prevents scalding in the event of hot or cold water shut off

In case of hot or cold water failure, the valve will shut down as per the relevant standard

Unique cartridge is highly resistant to calcium build-up, even in hard water areas

Other information

5 Year guarantee (12 months on serviceable moving parts from the date of purchase)

Features

Brand
NUIE
Material
Brass
Intended use of the tap
Shower
Shape
Rectangular
Height
30 cm
Tap activation mechanism
Mechanical
Thermostatic mixer
Yes
Weight
3.5 kg
Pressure
3 bar
Concealed tap
Yes
Wall-mounted tap
Yes
Tap head only
Yes
Type of installation method
Freestanding
Tap type
Dual-lever mixer
ManoMano Reference
ME42769201
MMID
688548566742
Product code
SANTR02
EAN
5056211898115
