Schneider 16725 - DuoLine XE Click Circuit Breaker 1P+N 10A - C curve - plug-in

Name: Schneider 16725 - DuoLine XE Click Circuit Breaker 1P+N 10A - C curve - plug-in
Brand: SCHNEIDER ELECTRIC
SKU: 16725
Price: 19.89 GBP
Availability: InStock
Rating: 4.51 (55 reviews)

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by AVB Negoce

Product information

Description

Circuit Breaker Application: Distribution. Product range: DUOLINE. Product type: Circuit breaker. Short device name: D'clic XE. Description of poles: 1P + N. Number of protected poles: 1. Neutral pole position: Left. In rated operating current: 10 A at 30 °C. Network type: AC. Trigger technology: Thermal-magnetic. Tripping curve: C. Breaking capacity: 3000 A Icn in accordance with EN 60898. 230 V AC.

Features

Brand
SCHNEIDER ELECTRIC
Amperage
10 A
Environmental certification
NF Environment
Pcs per pack
1
Tripping curve
C
Circuit breaker function
Two pole
Nominal intensity
AC
Material
Plastic
Number of terminals
1
Weight
2000 g
Breaking capacity
3 kA
Voltage
230 V
Type of connection
Plug-in
Circuit breaker type
Breaker switch
ManoMano Reference
ME57453922
MMID
258122837327
Product code
16725
EAN
3303430167259

Customer reviews

4,5

/ 55 Reviews

Reviews verified by ManoMano

JJean-Luc

Published on 24/02/2023, France

At the top super product fits very easily in a Schneider board. No need for advanced knowledge in electricity to connect it. The phase and the neutral very well identified and snapping of the wires automatically without screwdriver. I recommend

MManoMano Customer

Published on 15/07/2017, France

Be careful to understand the presentation of the product. This circuit breaker plugs into a dedicated support. It cannot be mounted on a "standard" switchboard. So good product certainly but which is not usable in my case

SStéphane

Published on 26/04/2023, France

Ask for my opinion when my package is in Lille instead of Fontaine la mallet (seine maritime). Ask me when you find it or send it back!

MManoMano Customer

Published on 17/06/2020, France

Obviously when we wait for delivery times are always long but with MANOMANO in general it does not last. Congratulations to the team, the product complies with the request. The price is very competitive compared to what is found elsewhere on the Internet. Once again bravo MANOMANO ............; which I recommend.

MManoMano Customer

Published on 09/04/2020, France

Meets my expectations. Attention provided for mounting on a specific support. There are other models with combs for food.

Eeric

Published on 21/04/2021, France

Quick installation by the plug-in concept ... I like
