Wire Rope Bulldog Grips Stainless DIN741 10MM (Marine Grade Boat Cable Clip Clamp)

Name: Wire Rope Bulldog Grips Stainless DIN741 10MM (Marine Grade Boat Cable Clip Clamp)
Brand: SECUREFIX DIRECT
SKU: SFSSWRG10
Price: 5 GBP
Availability: InStock

Sold by SecureFix Direct

Product information

Description

General description

Wire Rope Bulldog Grips are designed for secure and reliable use with wire ropes, particularly in marine environments. Made from 316 Grade Stainless Steel, these grips offer excellent rust protection, making them ideal for boats, yacht rigging, and public areas. They are primarily used for creating loops in wire rope.

Technical specifications

Size: 10MM

Metal: 316 Grade Stainless Steel

Product Code: SFSSWRG10

Dimensions:

A (MM): 22

B (MM): 10.5

C (MM): 16

D (MM): 8

E (MM): 46

F (MM): 16.5

G (MM): 34.5

Installation

Prior to fitting, grease the threads on the nuts and bolts.

Ensure spacing between grips is at least 6 times the diameter of the rope.

Orient the grip correctly, placing the 'U' bolt on the unloaded end of the rope.

Tighten each nut evenly and in turn to achieve the recommended torque settings.

Leave unused for 24 hours and check torque setting again, re-tightening if necessary.

After the first application of load, re-check torque setting and re-tighten if necessary.

Periodically check the torque setting during service.

Features

Brand
SECUREFIX DIRECT
Material
Stainless steel
Colour
Multicolour
Certification body
DIN
Warranty
1 year(s)
