XHM131 Photosensitive Relay Module No Adjustable Light Induction Light Delay Switch (12V)
Of which environmental contribution £0.01 including VAT.
Sold by Sinocor GmbH
You may also like
Compare with similar items
Product information
Description
1. With adjustable delay and light sensitivity functions, the light sensor is flicker-free. With relay and delay functions, when the light is dimmer than the brightness set by the potentiometer, the relay switch is automatically activated. It can be used for various light detection alarms, light control delay switches, brightness detection switches, and various streetlights. It automatically turns on at night and off during the day, and can be used to control automatic headlights, stage lights, LED lights, and traffic lights.
2. Adopts imported chip control, ensuring stable and reliable quality. It can achieve automatic light detection and brightness detection, and the brightness detection threshold can be adjusted via the potentiometer.
3. The power supply section has diode protection, a filter capacitor, an anti-interference capacitor, and a 7805 voltage regulator chip, which can provide a stable voltage and prevent the module from burning out when the power supply is reversed.
4. Equipped with a precision adjustable potentiometer for better adjustment of sensitivity and delay time; power supply and relay insertion instructions are included.
5. The module is equipped with a high-power relay, which can control a current load of 10A; it also comes with a 50cm long photoresistor.
6. The module has a delay, and the delay time can be adjusted to resolve the relay flicker issue when the light is at the switching point.
7. The new light-controlled delay module is equipped with a multi-turn precision adjustable potentiometer. Sensitivity and delay can be precisely adjusted to the appropriate range, and the application is stable.
Item Type: Photoresistor Relay Sensor
Material: Plastic
Model: XH-M131
Color: As Pictures Shown
Performance Parameters:
Optional Power Supply: DC12V, DC5V
Quiescent Current: 12mA, 15mA
Maximum Power Consumption: 72mA, 45mA
Relay Load Capacity: 250V 10A (AC), 30V 10A (DC)
Ambient Temperature: Delay Range: Connected to S2, adjustable delay from 1 to 20 seconds; without S2, adjustable from 1 to 200 seconds seconds.
2. Adopts imported chip control, ensuring stable and reliable quality. It can achieve automatic light detection and brightness detection, and the brightness detection threshold can be adjusted via the potentiometer.
3. The power supply section has diode protection, a filter capacitor, an anti-interference capacitor, and a 7805 voltage regulator chip, which can provide a stable voltage and prevent the module from burning out when the power supply is reversed.
4. Equipped with a precision adjustable potentiometer for better adjustment of sensitivity and delay time; power supply and relay insertion instructions are included.
5. The module is equipped with a high-power relay, which can control a current load of 10A; it also comes with a 50cm long photoresistor.
6. The module has a delay, and the delay time can be adjusted to resolve the relay flicker issue when the light is at the switching point.
7. The new light-controlled delay module is equipped with a multi-turn precision adjustable potentiometer. Sensitivity and delay can be precisely adjusted to the appropriate range, and the application is stable.
Specification:
Condition: 100% Brand NewItem Type: Photoresistor Relay Sensor
Material: Plastic
Model: XH-M131
Color: As Pictures Shown
Performance Parameters:
Optional Power Supply: DC12V, DC5V
Quiescent Current: 12mA, 15mA
Maximum Power Consumption: 72mA, 45mA
Relay Load Capacity: 250V 10A (AC), 30V 10A (DC)
Ambient Temperature: Delay Range: Connected to S2, adjustable delay from 1 to 20 seconds; without S2, adjustable from 1 to 200 seconds seconds.
Package list:
1 x photoresistor relay sensorFeatures
- BrandTEHTUY
- Length1 cm
- Width1 cm
- Height1 cm
- Weight100 g
