Insulation comes in a variety of forms but all forms of insulation have the same purpose – to avoid the warmth generated by your heating system flying out the window or through the roof! Among the most common options are insulation boards, rolls, blow-in insulation or even expanding foam for gaps and other hard-to-reach spots. Your insulation may also be backed up by products like pipe lagging or window seals. There are five main groups of insulating materials.
Mineral insulation is the most common option as it provides good thermal insulation and soundproofing properties. Included in this category are materials like glass wool, rock wool and cellular glass.
Synthetic insulation includes materials like expanded polystyrene, extruded polystyrene, polyurethane, polyisocyanurate and phenolic. These materials are what is known as foamed plastics.
Concrete block insulation involves using blocks filled with insulating materials. Thermal plasterboard is based on a similar concept. These forms of insulation can only be installed in new constructions or as part of renovation work.
Natural insulation is made of animal-based fibres such as sheep wool or duck down, or plant-based fibres such as hemp, cellulose wadding or wood wool.
Insulation foil is known by a number of different names such as multifoil insulation, radiant barriers, reflective insulation, and so on. This type of insulation is made up of aluminium sheets or aluminium polyethylene film. Insulation foil is often crticised due to its debatable performance and price.
Insulation can be applied to the outside of your home or the inside. It can cover any surface from floor to ceiling, including walls, doors, windows, roofs and loft spaces. It's possible to install insulation foil both during construction and post-build.
The insulating power of materials, or their thermal resistance, is measured by their R value in units of m² K/W. The higher the R value, the more effective the insulation; R = 0 is the lowest value while R ≥ 7.5 equates to effective insulation. In short, you need a high R value to ensure your insulation performs as expected. Whether you're insulating a new or older property, take care to ensure a minimum R value is reached.
Got a new house in construction? Go for insulation with a thermal resistance of R 8m² K/W for the roof and R 4m² K/W for the walls, roof gables and ground floor.
If you're hoping to make your home more energy efficient, improving the quality of your insulation is a must. Here are a few guidelines to help you out:
Of course these are just guidelines – be sure to follow the advice of industry experts when it comes to minimum R values.
It's also important to think about the flammability of insulating materials which is governed by the fire classification standard EN 13501-1. The classifications are as follows:
Be sure to check the legislation for each room you have to insulate. The rules may change depending on whether you're dealing with a private home or a public space.
The lambda value (or λ-value) measures the quantity of heat that can be conducted through a material within a certain amount of time. Thermal conductivity is measured in W m/K. But why exactly do we need to talk about thermal conductivity? The answer is very simple – it's all about the thickness of your insulation. Bear in mind that the lower the lambda value (or λ) the thinner the material and the higher the performance. To give you a quick idea, a λ-value of 0.06 is considered quite poor while insulation with a λ-value of 0.02 is considered effective. A low lambda value signifies low thermal conductivity meaning better insulation.
On the opposite end of the scale, the higher the thermal resistance (or R value), the more effective the insulation. If this is all sounding a bit complicated, don't worry – all these details will be provided in the product specifications. If you're looking to compare two types of insulation with the same thickness, you just need to divide the thickness of the material by the R value to find the lambda value:
In summary, the most insulating material will have a high R value and a low lambda value. It's up to you to find the right the right solution by weighing up factors like budget, space and surface type!
High-quality external insulation allows you to save energy and money. What's more, it's good for the planet! If you are in the process of building a new house, external insulation is a great call. This type of insulation is particularly beneficial if you have limited space inside the house. Your choice of insulating materials in this case will be:
As you may have guessed, you'll need a range of equipment to install external insulation including:
It's also possible to invest in waterproofing products to make your walls and roof more moisture- and mould-resistant – or else you might find yourself having to insulate the inside of your home, too!
Internal insulation can be flexible, semi rigid, rigid or foam-based. It can be installed using adhesive or fixings, depending on the type of insulation you choose. A vapour barrier should be fitted over your insulation before your final wall covering is installed whether this be plasterboard or wood panelling. Let's take a quick run through of the most common insulating materials used indoors.
Interior insulation comes in the following formats:
As a reminder, thermal bridging is the movement of heat across an object that is more conductive than the materials around it. It happens in building where there is a direct connection between the inside and outside.
Thermal bridging usually occurs:
The location of your thermal bridges will determine how to deal with them:
If you have the choice between internal and external insulation, go for external insulation. This option is more expensive and has to be installed before your final exterior wall covering. However, it is highly effective at eliminating thermal bridges and doesn't take up any room indoors. Internal insulation is the cheaper solution. It can be installed in any type of home and the range of insulating materials on offer is huge. The downside of internal insulation is that you lose part of your interior space and it is trickier to tackle thermal bridging.
No matter which type of insulation you choose, it is highly recommended to cut the material as precisely as possible to prevent heat loss at any point in the walls, ceilings or between floors.
In addition to providing thermal insulation, most insulating materials also offer some acoustic insulation though this does vary. If you think that the material you have chosen is not providing enough soundproofing, double up with floor or wall underlay. In terms of regulations, it's always best to read up on materials before you invest!
