Draper 150L 2.2kW (3HP) Belt-Driven Stationary Air Compressor – 150L Capacity, 230V, Model 55304

Name: Draper 150L 2.2kW (3HP) Belt-Driven Stationary Air Compressor – 150L Capacity, 230V, Model 55304
Brand: DRAPER
SKU: DA150/369S
Price: 655.33 GBP
Availability: InStock

Sold by GravaHaus and 2 other sellers

Product information

Description

General Description

This is a high-capacity belt-driven air compressor designed for workshop use. It features a durable thermal motor protection overload, an on/off pressure switch, a pressure regulator, and a pressure gauge. The compressor is equipped with a quick euro coupling outlet for easy connection of air tools and accessories.

Technical Specifications

Tank Capacity: 150 liters
Motor Power: 2.2 kW (3.0 HP)
Air Displacement: 13.03 CFM (369 L/Min)
Free Air Delivered (FAD): 8.44 CFM (239 L/Min)
Input Current: 13A
Speed: 1100 rpm
Maximum Pressure: 145 psi (10 bar)
Dimensions: 1280 x 480 x 950 mm
Weight: 98 kg

Compatibility and Accessories

Compatible with various workshop air tools and accessories that utilize a euro coupling connection

Installation

Ensure the compressor is placed on a stable, level surface in a well-ventilated area
Connect the air outlet to your tools using a compatible euro coupling
Check all connections and ensure safety devices are properly installed before operation

Usage

Switch on the compressor using the on/off pressure switch
Adjust the pressure regulator to the desired pressure for your tools
Use the pressure gauge to monitor the air pressure during operation
Turn off the compressor when not in use and drain moisture if necessary

Other Information

This compressor is suitable for continuous workshop use and heavy-duty applications. Regular maintenance is recommended to ensure optimal performance and longevity.

Features

Brand
DRAPER
Length
1 cm
Width
48 cm
Height
95 cm
Weight
90 kg
