230V MAGNETIC DRILL DRILLING MACHINE 1650W HOLZMANN MBM450LRE

Name: 230V MAGNETIC DRILL DRILLING MACHINE 1650W HOLZMANN MBM450LRE
Brand: HOLZMANN
SKU: 27979
Price: 614.68 GBP
Availability: InStock
Rating: 4.5 (2 reviews)

Sold by GLS72

Often purchased together

Product information

Description

General description

For tapping and threaded hole applications, the 230V Magnetic Drill Drilling Machine 1650W Holzmann MBM450LRE is perfect for treating bulky steel workpieces. It enables mobile treatment with precise guidance and is effective for vertical drilling. The machine can be clamped to any steel part through the activation of the electromagnet, ensuring no shifting during operation. The magnet provides safety during overhead work, making it a preferred choice in the building industry, bridge construction, and shipbuilding. This multifunctional unit features right and left run capabilities, adjustable speed, speed control, and a thread cutter.

Technical specifications

Motor power: 1650 W

Voltage: 230V / 50 Hz

Speed: 100-250 / 180-450 min-1

Spiral drill max. drilling depth: 110 mm

Core drill max. drilling depth: 35 mm

Spiral drill max. Ø: 19 mm

Weldon shank: MK2 / MT2

Magnetic force: 15000 N

Max. countersunk-head Ø: 22 mm

Magnet base dimensions: 170x80x50 mm

Max. thread size: M18

Core drill max. Ø: 45 mm

Distance quick release tool holder to base: 240 mm

Gross weight: 14 kg

Net weight: 12 kg

Features

Brand
HOLZMANN
Power
1650 W
Number of speeds
2
Voltage
230 V
Drill bit/chuck compatibility
Morse taper 2
Chuck diameter
19 mm
Tapered shank
Yes
Length
18 cm
Magnetic
Yes
Frame material
Steel
Material
Steel
Weight
15 kg
Chuck
Morse taper shank
Variable speed
Yes
ManoMano Reference
ME2340261
MMID
714714238277
Product code
27979
EAN
9120058371608

Customer reviews

4,5

/ 2 Reviews

Reviews verified by ManoMano

MManoMano Customer

Published on 09/11/2020, Spain

It is a product of good quality and price. Includes drill holder, deposit for oil-coolant. It comes in a suitcase so you can have everything well collected.
