3,000lb (1,361kg) 12v Military Grade Winch. 15.5m x 5mm Dyneema Rope, Remote Controls. Boat Trailer, Marine.

Name: 3,000lb (1,361kg) 12v Military Grade Winch. 15.5m x 5mm Dyneema Rope, Remote Controls. Boat Trailer, Marine.
Brand: WINCHMAX
SKU: WM300012VSSMILSPECSYN
Price: 199.95 GBP
Availability: InStock

Sold by Winchmax Ltd

Product information

Description

General description

3,000lb (1,361kg) Military Grade 12V Winch designed for heavy-duty applications.

Includes a 15.5m x 5mm Dyneema SK75 synthetic rope and twin wireless remote controls.

Ideal for use on boat trailers, ATVs, and light utility vehicles.

Technical specifications

Single Line Rated Pull: 3,000lb (1,361kg)
Motor: 12V 1.5hp permanent magnetic motor
Control: Remote rocker switch with handlebar mount
Gear Train: 3 stage planetary
Gear Reduction Ratio: 136:1
Clutch: Cam activated free spool
Braking Action: Automatic in the drum
Drum Size: Diameter 50mm (2.00”), Length 75mm (2.9”)
Drum Finish: Aluminium
Cable: 15.5m x 5mm Dyneema SK75 synthetic rope
Hook: Clevis hook 1/4 inch, black
Fairlead: One-piece billet aluminium hawse fairlead
Battery: Recommended 12Ah minimum for winching
Battery Leads: 6 gauge, 1.7m (67”) 15mmsq - 4.2mm Diameter
Winch Finish: Matt black (low light paint)
Weight (GW): 10kg (22lb)
Overall Dimensions (LxWxH): 339 x 110 x 114 mm
Mounting Bolt Pattern: 120 x 76 mm
Motor Current: 15-200A
No Load Line Speed: 8.3m/min (27.2 ft/min)

Usage

Designed for heavy-duty lifting and pulling tasks.

Can be used effectively with boat trailers, ATVs, and light utility vehicles.

Other information

Includes a heavy-duty one-piece solenoid, IP67 waterproof design, and upgraded water seals.

Industry-leading lifetime warranty on mechanical components and 3 years warranty on electrical components.

Features

Brand
WINCHMAX
Origin
Made in China
Colour
Black
Maximum load
1361 kg
Remote operation
Yes
Cable diameter
5 mm
Supplied with hauling pulley
Yes
IP rating
IP67
Work cable length
15.5 m
Material
Steel
Operating Mode
Electric
Weight
10 kg
Presence of brake
Yes
Power
1119 W
Power supply
Electric
Voltage
12 V
Winch operating type
Straight Line Pull
Sold with cable
Yes
ManoMano Reference
ME41603281
MMID
551668673151
Product code
WM300012VSSMILSPECSYN
EAN
8438569491304

Advice from

Winch buying guide

A winch is a lifting and pulling tool. Are you the Hulk? Can you lift a heavy load yourself? A winch is essential. A rope, cord, or cable attached a drum winds up and raises or pulls a load on the other end. Depending on usage, they can be portable, stationary, manual, electric, or hydraulic.
