General description
The ANNKE 5MP 16CH Outdoor CCTV System is a comprehensive surveillance solution featuring 16 IP cameras equipped with advanced technologies for enhanced security. This system supports two-way audio, infrared night vision, and intelligent motion detection, ensuring reliable monitoring day and night. With a 1TB hard drive for storage, it allows for extensive recording capabilities and remote access via mobile devices and PCs.Technical specifications
- NVR: Supports up to 12MP resolution for live view, recording, and playback
- Video Output: HDMI up to 4K (3840 × 2160), VGA up to 1080p
- Video Compression: H.265+/H.265/H.264+/H.264
- IP Video Input: 16CH PoE
- Max Recording Resolution: Up to 12MP (4096 X 3072)@30fps
- Max Playback Resolution: Up to 12MP (4096 X 3072)@30fps
- Dimensions (NVR): 15.2” X 12.4” X 2.0” (385 X 315 X 52 mm)
- Weight (NVR): 6.6 lbs (3 kg)
- Camera: 1/3" Progressive Scan CMOS sensor
- Max Camera Resolution: 3K (3072*1728) at 20fps
- Lens: 2.8 mm
- Min. Illumination: Color: 0.005 Lux, B/W: 0 Lux with IR
- Operating Temperature: -22 °F to 140 °F (-30 °C to 60 °C)
- IP Rating: IP67 (weatherproof)
- Weight (Camera): Approx. 340 g (0.7 lb)
- Dimensions (Camera): Ø 110 mm × 102.7 mm (Ø 4.33" × 4.04")
Compatibility and accessories
- Supports up to 16 IP cameras with PoE
- Compatible with third-party network cameras
- Storage: Built-in microSD/SDHC/SDXC slot, up to 512 GB
- Hard Drive Capacity: Up to 8 TB for each disk (2 SATA interfaces)
Installation
- Easy installation with PoE support for camera connectivity
- Remote access setup via Annke Vision app for mobile devices
Usage
- Real-time monitoring with two-way audio functionality
- Intelligent motion detection with alerts for human and vehicle detection
- Remote viewing and playback through mobile devices and PCs
