Chain Block and Geared Trolley Combination 5T 6M (Beam Girder Lift Tackle Manual)

Name: Chain Block and Geared Trolley Combination 5T 6M (Beam Girder Lift Tackle Manual)
Brand: SECUREFIX DIRECT
SKU: SFCCBGT53
Price: 380 GBP
Availability: InStock

Sold by SecureFix Direct

Product information

Description

General description

This Combination Chain Block and Geared Trolley is designed for lifting heavy loads with ease and precision. With a safe working load of 5 tons (5000 kg) and a lift height of 6 meters (20 feet), this product is ideal for various lifting applications. The geared trolley allows for attachment to steel beams, acting as an adjustable lifting point for the chain block, making it a convenient all-in-one solution.

Technical specifications

Safe Working Load: 5 Ton (5000 kg)

Lift Height: 6 Metres (20 Feet)

Hand Chain Effective Working Length (EWL): 5.8 m

Load Chain Diameter: 10 mm

Trolley Dimensions: 365 mm x 385 mm

Overall Height: 520 mm

Recommended Beam Size: 120 mm - 215 mm

Conforms To: BS EN 13157: 2004+A1: 2009

Usage

This combination chain block and geared trolley is suitable for lifting heavy loads in various settings, including construction sites and warehouses. The hand chain and gear combination allows for smooth operation and precise control during lifting tasks.

Other information

Safety hooks are drop forged and heat treated for enhanced safety and durability.

Supplied with a test certificate.

Please note that the color may vary; contact us if a specific finish is required.

Features

Brand
SECUREFIX DIRECT
Material
Two-material
power supply
Manual
ManoMano Reference
ME73900742
MMID
340213502394
Product code
SFCCBGT53
EAN
0600988577848

Advice from

Hoist buying guide

A hoist can be manual, electric, pneumatic or hydraulic. With the manual models, the hoist is composed chains and can include a lever. It allows to lift loads of 500 kg, 2 tons, 3 t or 5 t. The electric hoist offers more comfort and is often move on a trolley. It can efficiently lift and lower loads with precise accuracy.
