General description
This R255SMS+ Evolution Mitre Saw is designed for precise crosscut, bevel, mitre, and trench cuts in various materials including wood, wood composites, plastics, and metal. Powered by a robust 2000W motor (240V), it features a 255mm tungsten carbide tipped (TCT) Multi-Material blade, offering a crosscut capacity of 300mm x 80mm and cut accuracy within +/- 0.5 degrees. The saw allows for bevel tilts from 0 degrees to 45 degrees and mitre angles from 50 degrees to 50 degrees, making it a versatile tool for both job sites and home projects.Technical specifications
- Motor (110V 50Hz): 1600W
- Motor (240V 50Hz): 2000W
- No Load Speed: 2500 min-1
- Max. Mitre: 50 degrees - 50 degrees
- Max. Bevel (Left): 45 degrees
- Blade Diameter: 255mm
- No. of Teeth: 28
- Bore: 25.4mm
- Kerf: 2mm
- Max. Cross Cut (0 degrees x 0 degrees): 300mm x 80mm
- Max. Bevel Cut (0 degrees x 45 degrees): 300mm x 45mm
- Max. Mitre Cut (45 degrees x 0 degrees): 210mm x 80mm
- Max. Compound Cut (45 degrees x 45 degrees): 210mm x 45mm
- Mild Steel Plate (Max. Thickness): 6mm
- Mild Steel Box Section (Max. Wall Thickness): 3mm
- Product Dimensions: 360mm x 705mm x 730mm (with saw head down)
- Product Weight: 15.3 kg
- Sound Pressure Level LPA: 110V: 95.8 dB(A) / 220-240V: 95.8 dB(A)
- Sound Power Level LWA: 110V: 108.8 dB(A) / 220-240V: 108.8 dB(A)
- Laser Class: Class 2
- Laser Output Power (Max): <1mW
- Wave Length (Nm): 650
Compatibility and accessories
- Compatible with 255mm Multi-Material Cutting TCT Blade
- Compatible with 255mm Diamond Masonry Cutting Blade
- Compatible with 255mm Wood Cutting Blade
- Includes: 1 x RAGE® Multipurpose Circular Saw Blade 255 x 25.4mm x 28T, 1 x 3 Piece Toe Clamp, 1 x Work Piece Front Clamp, 1 x Dust Bag, 1 x Dual Ended Allen Key 4 & 6mm
Installation
- Machine Table Extensions included for enhanced cutting capacity
- Easy setup with included rotary table and neck
- Dust port adaptor for vacuum extraction
Usage
- Ideal for cutting a variety of materials including mild steel, wood with embedded nails, aluminium, plastic, and copper
- Laser guidance for optimum accuracy
- Ambidextrous, ergonomic horizontal trigger for comfortable grip
Other information
