Evolution S355CPS 355mm Metal Cutting Chop Saw With TCT Blade (110V)

The S355CPS Metal Cutting Chop Saw is ideal for cutting box section, angle iron, pipe, & sheet metal including roofing sheets. It leaves an instantly workable finish that is ready to weld. Cuts come off the saw cool to the touch and it produces virtually no sparks, making is safer, faster, cleaner and easier to use than abrasive wheel cutters.

If you're sick of waiting for the bandsaw to finish your big cuts, had enough of abrasive wheels and having to clean up every cut before you can start welding? Then it is time for the Evolution S355CPS Metal Cutting Chop Saw. Faster, more accurate cuts that are ready to weld straight off the saw. With 130mm maximum cut depth from its 355mm carbide-tipped blade.

• Heavy-duty cast aluminium base with integrated wear plate & bench mounting holes.
• Quick-release vice with robust square-threaded rod for fast & secure clamping.
• Accurate & durable cast steel vice with 0 degrees - 45 degrees mitre capacity & locking pin.
• Compact design with a head lock down pin & carry handle for easy transportation.
• Chip collection tray for a cleaner, safer working environment.
• Ergonomic, ambidextrous trigger with comfortable textured grip.
• Attachable ‚Äö√Ñ√≤v i shape block included for secure clamping of round & square tube.
• Easy blade change with integrated tool storage.

Specifications

Motor (240V 50Hz):2200WMotor (110V 50Hz):1600WSpeed No Load:1550 min^-1 Max. Bevel (Left):45 degreesCable Length:3mBlade Dia.:355mmNo. of Teeth:66Bore:25.4mm / 1 In.Kerf:2.4mmMild Steel Plate (Max Thickness):6mmStainless Steel Plate (Max Thickness):5mmSquare Tube at 90 degrees (Mild Steel):120 x 120mmSquare Tube at 45 degrees (Mild Steel):89 x 89mmRectangle Tube at 90 degrees (Mild Steel):95 x 180mmRectangle Tube at 45 degrees (Mild Steel):78 x 110mmRound Tube at 90 degrees (Mild Steel):√ò 130mmRound Tube at 45 degrees (Mild Steel):√ò 105mmMinimum Cut Off Piece Length:8 mmPackaging Dimensions:470 x 575 x 374mmProduct Dimensions:410 x 530 x 310mmProduct Weight:23.1 kgPackaged Weight:27 kgSound Pressure Level L_PA:94.9 dB(A)

K:3dB(A)Sound Power Level L_WA:107.9 dB(A)

K=3 dB(A)Items Supplied

66 Tooth Mild Steel TCT BladeHex Key 8mm (Blade Change)V-BlockCompatible With

GW355TCT-60 - 355mm Wood Blade

355mm Diamond Blade

355mm Mild Steel Cutting Blade

355mm 90T Stainless Cutting Blade

355mm Multi-material Cutting Blade

355mm Aluminium Cutting 80T Blade
