Extractor fan Punto Evo Flexo MEX 100/4 LL 1S

(£140.49/pc)

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by creoven

Product information

Description

General description

The Punto Evo Flexo MEX 100/4 LL 1S extractor fan is designed for efficient air extraction in small spaces such as bathrooms and utility rooms. It features a sleek white housing made of UV-resistant plastic that does not yellow over time. The fan is equipped with a thermal overload protection system and an integral backdraught valve to prevent cold air from entering the space.

Technical specifications

Nominal size: 100 mm

Voltage: 230 V ~ 50 Hz

Wattage: 9 W

Current consumption: 0.052 A

Speed levels: 1

Revolutions per minute: 2175

Airflow rate: 90 m³/h

Sound pressure level Lp-3m: 26.9 dB(A)

Total pressure Pmax: 39.23 Pa

Max. temperature for continuous operation: +50°C

Protection class: IP45

Insulation class: II

Front cover dimensions: 173 x 173 x 50 mm

Total depth: 126 mm

Diameter duct connector: 98 mm

Weight: 0.6 kg

Installation

The extractor fan can be mounted on the wall or ceiling. An on/off switch must be provided on-site for operation.

Usage

This extractor fan is ideal for air extraction in small bathrooms, utility rooms, and similar spaces.

Features

Brand
VORTICE
Colour
White
IP rating
IP45
Material
Plastic
Air flow
90 m³/h
Integrated non-return valve
Yes
Duct diameter
100 mm
Height
17.3 cm
Silent model
Yes
Room type
Bathroom
For bathroom
Yes
Power
9 W
Pcs per pack
1
Ball bearings
Yes
Voltage
230 V
Type of lawn aerator
Intermediate
Type of installation method
For mounting
ManoMano Reference
ME8140654
MMID
452319074052
Product code
XEF100
EAN
8010300102238

Customer reviews

4,3

/ 43 Reviews

Reviews verified by ManoMano

Reviews summary

AI-generated content

Noise: It operates quietly during use.

Ddominique

Published on 16/03/2021, France

very good product, perfect silencer for cellar or bathroom

Llaure't

Published on 19/10/2022, France

The product is a little noisy once installed I find for a small bathroom and the instructions could be more explicit

4 people found this helpful

Jjean

Published on 07/02/2022, France

very quiet aerator, easy to install ideal for rooms (bathroom - wc) with a volume of 6 to 10m3.

AAristide

Published on 28/12/2023, France

I ordered this air extractor with the timer function and discovered that there is no timer setting. I paid a high price though.

1 person found this helpful

JJean Paul

Published on 16/06/2023, France

Meets my expectations perfectly. Aesthetic and silent.

2 people found this helpful

Ddavid

Published on 21/01/2021, France

COMPLIANT DESCRIPTION
