General description
Wall mounted fan EQ HD T Series is designed for heavy-duty applications, featuring an axial-flow construction that ensures high performance and durability. With a maximum airflow of up to 12,000 m³/h, this fan is ideal for ventilation in various environments, including industrial and commercial settings. The fan is constructed with a robust steel housing and intake grille, coated with epoxy for added protection.Technical specifications
- Voltage: 400 Volt ~ 50/60 Hertz
- Protection rating: IP55, protected against water jets
- Max. permissible temperature of transported air: +60°C
- Ball-bearing asynchronous motor, insulation class F
- Available models:
- EQ HD 25/4 T: 90 W, 0.3 A, 250 mm, 1400 RPM, 1450 m³/h, 120 Pa, 47 dB(A), 5.0 kg
- EQ HD 30/4 T: 120 W, 0.4 A, 300 mm, 1400 RPM, 2150 m³/h, 145 Pa, 52 dB(A), 6.1 kg
- EQ HD 35/4 T: 150 W, 0.5 A, 350 mm, 1350 RPM, 2900 m³/h, 155 Pa, 57 dB(A), 7.4 kg
- EQ HD 40/4 T: 280 W, 0.7 A, 400 mm, 1400 RPM, 4400 m³/h, 190 Pa, 61 dB(A), 9.5 kg
- EQ HD 50/4 T: 420 W, 0.9 A, 500 mm, 1300 RPM, 7500 m³/h, 195 Pa, 68 dB(A), 10.6 kg
- EQ HD 50/6 T: 120 W, 0.22 A, 500 mm, 800 RPM, 5200 m³/h, 60 Pa, 56 dB(A), 10.8 kg
- EQ HD 60/4 T: 650 W, 1.3 A, 600 mm, 1400 RPM, 12,000 m³/h, 200 Pa, 74 dB(A), 16.4 kg
Compatibility and accessories
- Reversible operation when used with a compatible reversing switch (not included)
Installation
- Designed for wall mounting
- Ideal for short ducts or direct extraction to the outside
Usage
- Suitable for industrial and commercial ventilation applications
- Effective for air circulation and extraction in various environments
Other information
