Extractor fan Punto Evo Flexo MEX 100/4 LL 1S T

Buying for your business?

Negotiated prices excl. VAT up to -20%

Create a pro account

Sold by creoven

Often purchased together

Product information

Description

General description

The Punto Evo Flexo MEX 100/4 LL 1S extractor fan is designed for efficient air extraction in small spaces such as bathrooms and utility rooms. Its sleek white housing is made from UV-resistant plastic, ensuring durability and a non-yellowing finish.

Technical specifications

Nominal size: 100 mm

Voltage: 230 V ~ 50 Hz

Wattage: 9 W

Current consumption: 0.052 A

Speed levels: 1

Revolutions per minute: 2175

Airflow rate: 90 m³/h

Sound pressure level Lp-3m: 26.9 dB(A)

Total pressure Pmax: 39.23 Pa

Max. temperature for continuous operation: +50°C

Protection class: IP45

Insulation class: II

Front cover dimensions: 173 x 173 x 50 mm

Total depth: 126 mm

Diameter duct connector: 98 mm

Weight: 0.6 kg

Other information

Adjustable shut-off timer (3-20 min): fan turns off after expiration of the pre-set time

Thermal overload protection

Integral backdraught valve prevents cold air from infiltrating the system

Mounting options: wall, ceiling

Features

Brand
VORTICE
Colour
White
IP rating
IP45
Material
Plastic
Air flow
90 m³/h
With timer
Yes
Integrated non-return valve
Yes
Duct diameter
100 mm
Height
13.7 cm
Silent model
Yes
Room type
Bathroom
Weight
600 g
For bathroom
Yes
Power
9 W
Noise level
26.9 dB
Pcs per pack
1
Ball bearings
Yes
Voltage
230 V
Type of lawn aerator
Classic
Type of installation method
For mounting
ManoMano Reference
ME7279963
MMID
186382252490
Product code
11314
EAN
8010300113142

Customer reviews

4,3

/ 43 Reviews

Reviews verified by ManoMano

Ddominique

Published on 16/03/2021, France

very good product, perfect silencer for cellar or bathroom

Llaure't

Published on 19/10/2022, France

The product is a little noisy once installed I find for a small bathroom and the instructions could be more explicit

4 people found this helpful

Jjean

Published on 07/02/2022, France

very quiet aerator, easy to install ideal for rooms (bathroom - wc) with a volume of 6 to 10m3.

AAristide

Published on 28/12/2023, France

I ordered this air extractor with the timer function and discovered that there is no timer setting. I paid a high price though.

1 person found this helpful

JJean Paul

Published on 16/06/2023, France

Meets my expectations perfectly. Aesthetic and silent.

2 people found this helpful

Ddavid

Published on 21/01/2021, France

COMPLIANT DESCRIPTION
