General description
The ANNKE 5MP Outdoor Video Surveillance Kit is a comprehensive security solution featuring an 8-channel NVR and four smart dual-light cameras. This system offers high-resolution video recording, advanced motion detection, and two-way audio capabilities, making it ideal for both residential and commercial use.Technical specifications
- NVR: Supports up to 12 MP resolution for live viewing, recording, and playback
- Camera: 3K resolution (3072*1728) at 20 fps
- Video Output: HDMI up to 4K (3840 × 2160), VGA up to 1080p (1920 × 1080)
- Video Compression: H.265+/H.265/H.264+/H.264
- Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Lens: 2.8 mm
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Angle of View: Horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114°
- Supplement Light Range: IR up to 30 m, White Light up to 20 m
- Operating Power: DC 12 V± 25%, max. 7.5 W; PoE (802.3af), max. 9 W
- Operating Temperature: -22 °F to 140 °F (-30 °C to 60 °C)
- Dimensions (Camera): Ø 110 mm × 102.7 mm (Ø 4.33" × 4.04")
- Weight (Camera): Approx. 340 g (0.7 lb.)
- Dimensions (NVR): 315 mm x 240 mm x 48 mm (12.4” x 9.4” x 1.9”)
- Weight (NVR): 1 kg (2.2 lbs) without hard disk
Compatibility and accessories
- Supports up to 8 IP cameras with PoE inputs
- Compatible with third-party network cameras
- Storage: Built-in microSD/SDHC/SDXC slot, up to 512 GB
- Hard Drive Capacity: Up to 8 TB
Installation
- Easy installation with PoE support for camera connections
- Includes necessary mounting hardware for outdoor use
Usage
- Remote monitoring via mobile app (iPhone, iPad, Android) and PC
- Real-time audio communication through built-in microphone and speaker
- Smart dual-light technology for enhanced night vision
- Motion detection with human and vehicle recognition to reduce false alarms
Other information
