General description
ANNKE Outdoor Video Surveillance Kit includes 8 high-definition 5MP IP cameras equipped with advanced features such as 2-way audio, motion detection, and color night vision. This comprehensive surveillance system is designed for both indoor and outdoor use, ensuring reliable security monitoring around the clock.Technical specifications
- Camera Sensor: 1/3" Progressive Scan CMOS
- Max Resolution: 3K (3072*1728), 16:9 aspect ratio
- Main Stream: 20 fps at 3072*1728, 25 fps at 1920x1080, 1280x720
- Substream: 25 fps at 1280x720, 640x480, 640x360
- Video Compression: H.265+/H.265/H.264+/H.264
- Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Lens: 2.8 mm
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Angle of View: Horizontal FOV 98°, Vertical FOV 54°, Diagonal FOV 114°
- Supplement Light Range: IR up to 30 m, White Light up to 30 m
- Operating Power: DC 12 V± 25%, max. 7.5 W; PoE (802.3af), max. 9 W
- Operating Temperature: -22 °F to 140 °F (-30 °C to 60 °C)
- Dimensions: 179 mm × 67.4 mm × 69.1 mm (7.1" × 2.7" × 2.7")
- Weight: Approx. 315 g (0.7 lb.)
Compatibility and accessories
- Supports up to 8 IP cameras with PoE inputs
- Built-in microSD/SDHC/SDXC slot, supports up to 512 GB
- Compatible with mobile devices (iPhone, iPad, Android) for remote monitoring
Installation
- Easy installation with PoE technology, reducing the need for additional power sources
- Includes a metal and plastic housing suitable for outdoor conditions
Usage
- Real-time security monitoring with 2-way audio
- Smart motion detection with human and vehicle recognition
- Remote access via mobile app or PC
- Color night vision with intelligent dual-light technology
