General description
The ANNKE Wired Video Surveillance Kit includes a 32-channel NVR and 24 night vision cameras, designed for comprehensive outdoor security. With advanced features such as email alerts, motion detection, and remote access via APP/PC, this system ensures reliable monitoring of your property.Technical specifications
- NVR Resolution: 12 MP
- Camera Resolution: 3840 × 2160 (4K Ultra HD)
- Camera Lens: 4 mm
- Field of View: Horizontal 78°, Vertical 38°, Diagonal 96°
- Video Compression: H.265+/H.265/H.264+/H.264/MPEG4
- Max Playback Resolution: Up to 12 MP
- Max Recording Resolution: Up to 12 MP
- Incoming/Outgoing Bandwidth: 256 Mbps
- Storage: Supports HDD up to 12 TB (4 SATA interfaces)
- Operating Power: DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W
- Operating Temperature: -22 °F to 140 °F (-30 °C to 60 °C)
- Dimensions (Camera): Ø121.4 mm × 97.6 mm (Ø4.78" × 3.84")
- Weight (Camera): 1.2 lb. (550 g)
- Dimensions (NVR): 17.5" X 15.7" X 2.8" (445 mm X 400 mm X 71 mm)
- Weight (NVR): ≤11 lbs. (5 kg)
Compatibility and accessories
- Supports up to 32 IP cameras (including 16 PoE channels)
- Compatible with microSD/SDHC/SDXC cards up to 512 GB
Installation
- Easy installation with PoE support for simplified wiring
- Includes 4 SATA interfaces for hard drives
Usage
- Ideal for outdoor surveillance with IP67 weatherproof rating
- Real-time audio monitoring with built-in microphone
- Advanced motion detection to minimize false alerts
