Coilovers for Ford Fiesta Mk6 & ST150 2001-2008 1.25 1.4 1.6 JH JD

Application:

for Ford Fiesta MK5 (often referred to as Fiesta Mk6) JD, JH 2001-2008

1.25 16V/1.3/1.4 16V/1.4 TDCi/ 1.6/1.6 16V/1.6 TDCi / ST150

Specification:

Adjustable height: Front & Rear

Front Lowering 30mm-75mm (depends on vehicle models)

Rear Lowering 30mm-65mm (depends on vehicle models)

Spring rate Front: 2.5 kg/mm(140 lbs/in)

Spring rate Rear: 2.5 kg/mm(140 lbs/in)

Spring length Front: 240 mm

Spring length Rear: 263 mm

Front spring inner diameter: 58-63 mm

Rear spring inner diameter: 52-84 mm

Spring Preload advised: 7-10 mm

Shock type: Twin tube

Warranty: 2 Years

Top mounts: Front and rear OE top mounts required

Feature:

1.  Lower height adjustable (depends on vehicle models)
2. Dust boot, solid rubber bump stops
3. Weight Saving Aluminum Components And heavy duty Steel Lower Mount Brackets
4. Simple install,  Easy to adjust.
5. Use the vehicle's original upper mounts (not included in our product kit).

Notice:

1. All modifications must be installed by licensed mechanics and in compliance with your local modification regulations.
2. Please ensure all components are tightened with correct torque specifications (which can be found in the vehicle service manual)before and after installation. Any loose nuts, bolts, or locks will cause noise. Do check and tighten before serious problems happen.
3. Impact wrench is prohibited during the installation, it will loosen or damage the product.
4. Examine the clearance between tires and suspension. ( The minimum clearance should be 4mm, otherwise, you need to add wheel spacers. Caution: It is not sufficient with torsion beam trailing arm axles)
5. We suggest regular maintenance for the coil-over, spray with some WD40 every 3-4 months will keep it smooth and clean, which helps to extend the lifetime.
