Rear Air Suspension Kit W/ Dual Gauge for Fiat Ducato Peugeot Boxer 1994-2024

Name: Rear Air Suspension Kit W/ Dual Gauge for Fiat Ducato Peugeot Boxer 1994-2024
Brand: MAXPEEDINGRODS
SKU: GG250912A58
Price: 257.4 GBP
Availability: InStock
Rating: 4.4 (10 reviews)

Sale

-10%

~~£286.00~~

Sold by maXpeedingrods GB

Product information

Description

General description

This Rear Air Suspension Kit with Dual Gauge is designed for various models including Fiat Ducato, Citroen Relay, Peugeot Boxer, and Citroen Jumper from 1994 to 2024. It is suitable for body types such as panel vans, tippers, motorhomes, campers, and box vans. This kit is compatible with both single and twin rear wheel configurations and can be used on front-wheel drive (FWD) or rear-wheel drive (RWD) chassis, excluding Alco type torsion bars chassis.

Technical specifications

Condition: Brand New

Chassis Type: All standard type

Placement on Vehicle: Rear left and right

Max loading: 4000 Kg

Air Spring Design height: 172 mm

Stroke: 140 mm

Extended: 230 mm

Compressed: 90 mm

Air Pump Power: 150W

Output Voltage: 12V

Maximum current: 10A

Maximum Working Voltage: 10 bar (1 MPa)

Compressor hose diameter: 0.72 m

Compressor cable diameter: 2.6 m

Compatibility and accessories

Compatible with Fiat Ducato, Citroen Relay, Peugeot Boxer, and Citroen Jumper (1994-2024)

Package includes:

2x Natural Rubber & Hi-tensile steel air spring bags

4x Galvanised heavy-duty mounting brackets

1x 12V air suspension compressor

1x Dual gauge

1x Air line (14 m)

1x Fuse harness

1x Y-type air line connector

Mounting bolts and air fittings

Installation

Professional installation is recommended for this aftermarket air suspension kit, which is designed to replace the original suspension system.

Usage

This air suspension kit enhances vehicle stability, restores original ride height, and improves ride quality. It ensures driving comfort and reduces tire wear.

Other information

Stress tested for durability and safety with over 5,000,000 cycles

Burst pressure ≥ 2.0 MPa for high compressive strength and reduced noise

100% air tightness guarantee

Temperature range: ≥ -40℃ / ≤ 70℃ (≥ -40°F / ≤ 158°F)

4-layer reinforcement construction for enhanced load support

High-quality steel used for load-bearing capacity and longevity

Dacromet surface treatment for excellent corrosion resistance

Features

Brand
MAXPEEDINGRODS
Warranty
2 year(s)
Shock absorber installation
Rear
Shock absorber only
Yes
Compatible chassis
Standard

Customer reviews

4,4

/ 10 Reviews

Reviews verified by ManoMano

Rruggero

Published on 06/07/2026, Italy

Excellent product. I installed it myself with a little expertise in one morning at work and a few tutorials. I've been using it for a few kilometers and it has changed the setup of my vehicle. Highly recommended!

MMassimo

Published on 12/06/2026, Italy

I just installed it on my camper, it seems well made, quite simple to assemble, for now everything is ok I will tell you later how it behaves if it resists or not.

MManoMano Customer

Published on 05/06/2026, Italy

Fast shipping, good packaging, complete kit, easy to install and very efficient

MManoMano Customer

Published on 22/05/2026, Italy

Excellent product, I recommend it

JJean Pierre

Published on 02/02/2026, France

Easy to install, well-presented product. Fast delivery. Time will tell how long it lasts.

AAbramo

Published on 02/02/2026, Italy

Easy assembly and functional
