Draper 02019 16-Speed 1100W Floor Standing Drill Press with 3-16mm Chuck and 1.8m Power Cable

Description

• The Draper 02019 is a 16-speed floor-standing drill with a 25mm drilling capacity, designed for professional use in workshops and home improvement projects. It features a sturdy construction with a steel motor casing and a lockable pulley cover for safety and durability. The drill includes a square table with a rack and pinion mechanism for smooth and precise height adjustments, making it suitable for various drilling tasks. Equipped with a No-Volt safety release switch, depth stop, and chuck guard, it ensures safe operation during use.

Specifications

• Drilling capacity: 25mm
• Chuck capacity: 3-16mm
• Spindle taper: MT2
• Number of speeds: 16 (160-3000 rpm)
• Spindle travel: 80mm
• Column diameter: 80mm
• Table size: 356 x 356mm
• Base size: 485 x 290mm
• Throat depth: 255mm
• Height: 1635mm
• Weight: 86kg

Compatibility and Accessories

• Compatible with standard 3-16mm drill chucks
• Includes a BS approved non-rewireable moulded plug and approximately 1.8 meters of cable

Installation

• Designed for floor-standing installation in workshops or garages
• Requires a stable, level surface for setup
• Ensure proper electrical connection with the supplied plug

Usage

• Suitable for drilling metal, wood, and plastic materials
• Adjust the table height and spindle speed according to the material and task
• Use the safety features such as the No-Volt switch, depth stop, and chuck guard during operation
