General description
Exclusive bundle direct from Evolution Power Tools - the Evolution R255SMS-DB+ 255mm Double Bevel Sliding Mitre Saw with Mitre Saw Stand and 60 Tooth Fine Wood Cutting Blade. With a 255mm blade and a huge 90mm x 300mm crosscut capability, the R255SMS-DB+ is the most capable and powerful Mitre Saw in the Evolution line-up. It features 2,000 watts of power and a multi-material blade that slices through wood, plastic, metal, and even reclaimed wood with embedded nails, offering best-in-class power and versatility. This double bevel mitre saw cuts 45° bevels in both directions, and includes an integrated laser cutting guide and positive bevel stops for accuracy. The durable die-cast aluminium base is tough enough to handle any material, making it the ultimate trade and workshop mitre saw.Technical specifications
- Motor (240V 50Hz): 2000W
- Motor (110V 50Hz): 1600W
- Speed No Load: 2600 min-1
- Max. Bevel L+R: 45° - 45°
- Max. Mitre: 50° - 50°
- Cable Length: 4m
- Blade Diameter: 255mm
- No. of Teeth: 28
- Bore: 25.4mm / 1 in.
- Kerf: 2mm
- Max. Cross Cut (0° x 0°): 300mm x 90mm
- Max. Bevel Cut Left (0° x 45°): 300mm x 52mm
- Max. Bevel Cut Right (0° x 45°): 300mm x 34mm
- Max. Mitre Cut (45° x 0°): 212mm x 90mm
- Max. Compound Cut Left (45° x 45°): 212mm x 52mm
- Max. Compound Cut Right (45° x 45°): 212mm x 34mm
- Mild Steel Plate (Max. Thickness): 1/4 in.
- Mild Steel Box Section (Max. Wall Thickness): 1/8 in.
- Product Dimensions: 570 x 545 x 385mm
- Packaging Dimensions: 575 x 545 x 385mm
- Product Weight: 18.24 kg
- Packaged Weight: 20.5 kg
- Sound Pressure Level LPA: 95.8 dB(A) K=3 dB(A)
- Sound Power Level LWA: 108.8 dB(A) K=3 dB(A)
Items Supplied
- 255mm (10 In.) 28 Tooth Multi-Material Cutting Blade
- Machine Table Extensions x2
- 6mm & 4mm Dual-Ended Hex Key
- Rotary Table And Neck
- Cutting Head
- Carriage Slides
- Mitre Locking Knob
- Mains Cable
- Guide/Clamp
- Self Tapping Cap Screw x1
- M6 x 16mm Socket Headed Screws x4 M5 x 12mm
- Socket Headed Screws x2
- Laser Lens Cap
- Cable Clip
- Slide Locking Knob
- Dust Port Adaptor
- Dust Collection Bag
- Quick Release Hold Down Clamp
- Instruction Manual
